Jet Engine; 3-Spool, Optional-Fan

?
Creation's quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 4.5k views
  • 20 likes
  • 445 downloads

3D model description

This is an Optional Fan with New Shape Blades for "Jet Engine, 3-Spool ".
https://cults3d.com/en/3d-model/tool/jet-engine-3-spool
This is designed to simulate for the latest engine's fan.

The Rotor Assy can be replaceable.

STL File (ws: with Special Support)
- Fan-Blade-New-CCW01ws.stl (Original: Fan-Blade201ws.stl)
- Note: Fan-Shaft01.stl and LP-Front-Stop101.stl are not changed.

3D printing settings

Printer setting (Recommendation) (used PLA):
- infill: 100%, Layer Height: 0.2mm, No support

Post printing:
- Take care to remove the Special Support for damaging of the blade.
- Finish blade edges and surfaces as required.

  • 3D file format: STL
  • Publication date: 2018/02/15 at 08:27

Tags

Creator

Designs 76
Downloads 6.4k
Followers 194

Retired Aircraft Engine Engineer
Aichi, Japan
"Aircraft Engine Museum by 3D Printer Models"
http://www7b.biglobe.ne.jp/~konchan77/

License

CC BY NC
