LOG CABIN BIRDHOUSE

?
Creation quality: 4.6/5 (12 votes)
Evaluation of members on the printability, utility, level of detail, etc.

3D model description

Yep! Another birdhouse design! :)

NOTE: FOR COMMERCIAL USE AND SELLING YOUR PRINTS, FULL ACCESS TO ALL MY MODELS AND EXCLUSIVE STLs JOIN MY PATREON:

https://www.patreon.com/PA1_MAKER

FEATURES:
-Very few supports (only on top beam and chimnee)
-All parts are already placed in the right orientation
-Large bottom door for cleaning between seasons
-3 diameters of entrance included: 28.5mm, 32mm, 38.5mm
-Detailed exploded view to help you with the assembly
-Big parts can be done with a layer height of 0.3 with no problem to speed up printing time. (House body on the pictures was made with 0.3 layer height)
-Sturdy and strong design, with thick walls that won't deform overtime.

Be sure to have your bridge settings at "ON".
For the small parts, use 4 walls. This will make a stronger piece.

Watch for over extrusion. If you're having some fitting problems, simply sand gently the parts to help them fit together. But with a good calibration, everything should be fitting together very well.

Can be hang or wall mounted.

This one is very close to the limits of a prusa mk3s bed. It will be ok on a ender 3 bed, but for prusa owners i suggest that you double check all big parts. At least you can scale them down by 1% to help if necessary.

SCALES :
100% - Will use m4 screws.
75% - will use m3 screws.

If you choose to hang it, you have two holes provided on the top beam.

If you have any problems, just send me a message.

Have fun!!!

For full access to all my models and for commercial license:
https://www.patreon.com/PA1_MAKER

LINKS to my other birdhouses:

Tooned Birdhouse V1.0
https://cults3d.com/en/3d-model/home/tooned-birdhouse-v1-0

Tooned birdhouse V2.0
https://cults3d.com/en/3d-model/home/tooned-birdhouse-v2-0

Caravan birdhouse V1.0
https://cults3d.com/en/3d-model/home/cute-caravan-birdhouse-pa1

Caravan birdhouse V2.0 (Woody)
https://cults3d.com/en/3d-model/home/cute-caravan-birdhouse-2-0-woody

Leprechaun's hat Birdhouse
https://cults3d.com/en/3d-model/home/leprechaun-s-hat-birdhouse-free-until-march-17

Classic Birdhouse
https://cults3d.com/en/3d-model/home/classic-birdhouse-easy-to-print

3D printer file information

  • 3D design format: STL and ZIP Folder details Close
    • BOTTOM.stl
    • CHIMNEE PART 001.stl
    • CHIMNEE TOP PART 002.stl
    • CHIMNEE TOP.stl
    • DOOR FRAME.stl
    • DOOR WINDOW.stl
    • DOOR.stl
    • ENTRANCE-28.5mm.stl
    • ENTRANCE-32mm.stl
    • ENTRANCE-38.5mm.stl
    • FRONT WINDOW FRAME.stl
    • FRONT WINDOW INNER FRAME.stl
    • FRONT WINDOW PANE.stl
    • LOG BODY.stl
    • LOG CABIN BIRDHOUSE.zip
    • LOG STACK.stl
    • METAL ROOF 002.stl
    • PERCH.stl
    • REAR STAND.stl
    • SIDE WINDOW FRAMES.stl
    • SIDE WINDOW INNER FRAME.stl
    • SIDE WINDOW PANES.stl
    • STEP.stl
    • TOP BEAM.stl

    Learn more about the formats

  • Publication date: 2022-03-28 at 07:20

Copyright

©

Tags

Creator

Having a lot of fun, designing a lot of stuff!!!! :)

Patreon for exclusive models and commercial license: https://www.patreon.com/PA1_MAKER
