  • Big_SpurGear.stl 44.997834 × 44.857407 × 5.0 mm
  • Box_Big.stl 123.552956 × 199.5 × 103.199997 mm
  • Box_Small.stl 123.552956 × 199.5 × 60.318485 mm
  • Geared_Hexagonal_Box_Big.stl 123.552956 × 199.5 × 103.199997 mm
  • Geared_Hexagonal_Box_Small.stl 123.552956 × 199.5 × 60.318485 mm
  • Outer_SpurGear.stl 103.41529 × 95.805115 × 3.0 mm
  • Small_SpurGear.stl 24.46973 × 24.544581 × 15.0 mm

Learn more about the formats
Publication date
Design number 1061497
Design author 3DTechDesigns
3DTechDesigns

3DTechDesigns

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

All 3DTechDesigns STLs are protected under Copyright Law.
When purchased on Cults3D you have the right to print it for personal use.
To legally sell prints of my designs a monthly active subscription on patreon is required:
https://www.patreon.com/3dtechdesigns

Another 100% print in place box with a geared closing mechanism.
The download includes a small and a big version of the box.

Allthough the box is print in place, it is also possible to print the parts seperatly. The parts easily snap-fit together afterwards. This can be used to achieve a multi-color print.

If your gear mechanism moves a bit stiff, you can use a small amount of lubricant, this makes a very smooth mechanism

3D printing settings

  • Minimum print-bed size: 200x200mm
  • no supports needed
  • print orientation is already correct, when loaded into slicer
  • in order to get the tolerances of the mechanism right, you should not go higher than 0.4mm nozzle and 0.3mm layer height
