enclosure_side_A_open.stl Free STL file Nema 17 right angle gearbox with spiral bevel gears・Design to download and 3D print
enclosure_side_A.stl Free STL file Nema 17 right angle gearbox with spiral bevel gears・Design to download and 3D print
enclosure_side_B_open.stl Free STL file Nema 17 right angle gearbox with spiral bevel gears・Design to download and 3D print
enclosure_side_B.stl Free STL file Nema 17 right angle gearbox with spiral bevel gears・Design to download and 3D print
spiral_bevel_gear_L.stl Free STL file Nema 17 right angle gearbox with spiral bevel gears・Design to download and 3D print
spiral_bevel_gear_R.stl Free STL file Nema 17 right angle gearbox with spiral bevel gears・Design to download and 3D print
Share
Add to
Make
?
Creation quality: 4.8/5 (4 votes)
Evaluation of members on the printability, utility, level of detail, etc.

Designer

dasaki

dasaki

3D model description

Experimental design to substitute dual Z axis motor setup in cartesian 3D printers.
Bearings are 605zz, threaded rods and nuts are M5.
Use white teflon grease to lubricate. No backslash thanks to spiral gears.
See it working here: https://youtu.be/-EybqXk5Lfg
