A1200 Mini Raspberry Pi4 and 3

After the A500 Mini has been launched, I decide to release the A1200 Mini for my PiMiga 2.0.

The A600 Mini is also availabe for you 23x23 bed, check my design ;)

Waht you need to build it ?

A 3D printer :D :D

BED : 30x30

Nozzle : 0.4 for all parts except badge => 0.1 or resin for better quality !

Layer Height : 0.15 and 0.2

Support : yes

Brim : as you want, but remember wrap effect !

Remember to check:

Support Z Distance

Support X/Y Distance

Retraction (distance/speed)

Z Hop Height

My settings => check the "Imp3D-Cura_settings-A1200 Mini.html" file

Hardware parts

• Bottom parts

  USB2.0 TYPE A => 4x MALE and 4x FEMALE : https://fr.aliexpress.com/item/1005001283232819.html

  RJ45 coupler => 1x : https://www.amazon.fr/VCE-CAT6A-Network-Coupleur-Femelle/dp/B07D28TC56/ref=sr_1_7

  RJ45 flat cable 15cm or 6" => 1x : https://fr.aliexpress.com/item/1005003995751089.html

  brass insert => x2 : M2x3 (for the RJ45 coupler)

  screws => x6 : M2x6 or M2x8 (for the RJ45 coupler)

  screws => x4 : M3x4 (for the Pi)

• Top parts

  LED => 2xRED,4xGREEN : https://fr.aliexpress.com/item/32951239560.html

  6x resistors => ~330ohms or ~470ohms (must be calculated)

  brass insert => x6 : M2.5x4

  screws => x6 : M2.5x6

• Glue for the keyboard => Humbrol Poly Cement (it smells bad, but perfect) : https://www.amazon.fr/Humbrol-AE4422-Accessoire-Mod%C3%A9lisme-Polystyr%C3%A8ne/dp/B0043F5KY4/ref=sr_1_4

• Sandpaper maybe, depend of your printer and skills ;)

For LED blinking, I use the PiLEDlights project from GitHUB : https://github.com/RagnarJensen/PiLEDlights

Only Amiga makes it possible !

^^

see the Cura 3d file ^^
