FORD PREDATOR GT500 V8 - ENGINE

?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

  • 8.3k views
  • 53 likes
  • 72 downloads
  • 2 collections
  • 1 make

Licence CULTS - Private Use
Last update 2023-11-04 at 16:05
Publication date 2023-01-17 at 16:41
Design number 1014940
3D design format
STL Folder details Close
  • A-C Compressor (pulley Poly-V).stl
  • Alternator (pulley Poly-V).stl
  • Alternatore.stl
  • Asticina olio.stl
  • Belt tensioner_1 (Poly-V).stl
  • Belt tensioner_2 (Poly-V).stl
  • Belt tensioner_3 (Poly-V).stl
  • Blower (pulley Poly-V).stl
  • Compressore A-C.stl
  • Crankshaft (pulley Poly-V).stl
  • Filtro aria a cono.stl
  • Filtro olio (filtro).stl
  • Filtro olio (portafiltro).stl
  • Monoblocco.stl
  • Perni (5x12).stl
  • Perni (5x36).stl
  • Perni (boccola 9x30mm).stl
  • Pompa acqua.stl
  • Puleggia (alternatore).stl
  • Puleggia (compressore A-C).stl
  • Puleggia (pompa acqua).stl
  • Punterie_DX.stl
  • Punterie_SX.stl
  • Scarico_DX.stl
  • Scarico_SX.stl
  • Starter motor.stl
  • Testata_DX.stl
  • Testata_SX.stl
  • Water pump (pulley Poly-V).stl
  • ___PREDATOR_Aspirazione (corpo farfallato).stl
  • ___PREDATOR_Carter anteriore.stl
  • ___PREDATOR_Compressore (base).stl
  • ___PREDATOR_Compressore (giunzione).stl
  • ___PREDATOR_Compressore (puleggia).stl
  • ___PREDATOR_Compressore (raccordo tubi).stl
  • ___PREDATOR_Compressore (tappo).stl
  • ___PREDATOR_Coppa olio.stl
  • ___PREDATOR_Pompa acqua (raccordo).stl
  • ___PREDATOR_Puleggia (albero motore).stl
  • ___PREDATOR_Puleggia rinvio.stl
  • ___PREDATOR_Volano.stl

Learn more about the formats

3D printer file info

3D model description

Ford predator V8 Supercharger engine, this incredible engine is equipped with an Eaton compressor that increases the power by over 200 HP, it is the engine installed on the Ford Mustang Shelby GT500, supercharged evolution of the legendary Ford Voodoo engine.

Update:
- Modified and improved the oil filter and its filter holder
- Exploded assembly drawings
- Added Poly-V pulley

The gearbox is not included, it is available separately.

FORD PREDATOR GT500 5.2 - GEARBOX TREMEC TR-9070 DCT https://cults3d.com/en/3d-model/gadget/ford-predator-gt500-5-2-gearbox-tremec-tr-9070-dct

GEARBOX TREMEC T56: https://cults3d.com/en/3d-model/gadget/ford-coyote-5-0-gearbox-tremec-t56

FORD COYOTE 5.0 - DRIVE SHAFT AND DIFFERENTIAL https://cults3d.com/en/3d-model/gadget/ford-coyote-5-0-transmission

EXHIBITOR SUPPORT FOR MOTORS https://cults3d.com/en/3d-model/gadget/exhibitor-support-for-motors

Disclaimer:
- The resale of my files is NOT allowed
- Printing for commercial use is NOT allowed
For authorizations and concessions please contact me here on Cults.

3D printing settings

The photos represent the engine made with a resin printer, some photos are renderings of the project I made.
It is possible to print with FDM printer at moderate speed but obviously the level of detail will be lower and in some cases the supports will be necessary.
These are my printing parameters using Elegoo printers and YAJO standard resin.

PRINTER............BASE EXPO....NORMAL EXPO....RES

JUPITER............37sec.............2,0sec.................0,050mm

MARS 2 PRO.......45sec.............4,5sec.................0,050mm

SATURN.............35sec.............3,5sec.................0,050mm

Change scale:

1/8 > 1/25 -32,00 %

1/8 > 1/24 -33,33 %

1/8 > 1/18 -44,44 %

1/8 > 1/12 -66,66 %

1/8 > 1/10 -80,00%
