Came across an unknown fact that the Babooshka costume worn by Kate in the 80’s was actually inspired by Chris Achilleos cover art of Raven in 1978. Having been a fan of both Chris’s and Kate’s work for a lot of years decided it was time to add Kate to my collection of Icons . .

Like the “SIMPLY MARILYN - BY SPARX” model available here;
https://cults3d.com/en/3d-model/art/simply-marilyn-by-sparx
I will not produce any adult themed parts for this sculpture.
However I am creating an Add-On’s pack to change the sculpture into Raven see end picture . . .

You will need to print two left hands if requiring the cape to remove and be replaced with a hand no cape.
2 Heads , one for cape fitting and one when cape not used.

I used colour changing paints on inside of cape as I always intended to fit the LED sequence of lights.
Her costume stripes with brush and fine marker pen, then micro glitter before clear coat, so lights would have the correct effect.

Based on Kate’s Measurements of 31(32A Cup)-24-33 and 5Feet 3inches or 160cm Tall (Flat Feet) the Model is 1/6th scale therefore would be 267mm standing.
So model in “Heels arm above head” 300mm or with base 317mm height.

Kate parts
1 Arm
1 Left Hand
1 right Boot
1 left Boot
2 Heads
1 Upper Torso
1 Lower Torso
1 Cape single Part
2 (Left & Right) pieces Cape
1 Base one piece
1 sword blade

14 items in total.

PURCHASE OF THESE FILES DOES NOT ALLOW SELLING STL FILES OR MODELS MADE FROM THE FILES. . . DOWNLOAD IS FOR SINGLE BUYER USE ONLY

I SHARE MY WORK FOR OTHERS TO ENJOY. . .PLEASE DO NOT SHARE THESE FILES ON SOCIAL MEDIA OR OTHER WEBSITES. LINKS TO THIS PAGE ARE ACCEPTED

All parts are cut files to fit build plate of small resin printers like the Photon or have separate files than the FDM versions included.
These orientations work for FDM printing but you may find a better orientation that reduces support.
All the parts have been printed and developed to print, A lot of prints have been produced to get the figures corrected and fault free.

Why cut into many smaller parts I have been asked?
1. If you try and assemble this, then paint it . .it would be difficult to paint into hidden areas, less masking when painting separate parts.
2. Smaller parts not only allow for Resin print at full scale, but also allow individual parts to use less supports than one larger part on FDM printers
So now you know!
Please do not scale down or adjust my recommended settings for infill etc. . . as you can see from the pictures this prints very well and I believe you will be pleased with the result when completed.
All of my models are only released when they can print! so please do not remix or "fix" faults in this model then republish! If there is a fault then let me know . . message me I will answer and fix problem. . apart from that print, make, enjoy.

3D PRINTING SETTINGS

Resin Printing;
Hollow 2.40 Raft 100%
Head, Boots & Left Arm

Hollow 2.70 Raft 100%
Upper & Lower torso

DO NOT Hollow
Left hand

FDM
Arm, Head, hand, sword blade,80% fill 0.12 speed 40
Rest at 0.16 30% fill, speed 50

ALWAYS dry assemble and “trim” parts prior gluing.
Look at the picture of how to assemble parts, so that you construct and paint separate before joining should you wish.
