"Route 76" Home Circuit for Turbo Racing 1/76 RC Car V2.0

This is a group of modules that can be used to create a racing circuit for the micro cars.

I have added 3 types of straight, each of them is 140mm long:
-Clear with just the road
-Start with finish line and 2 starting grids spots and a flag
-Grid further adds 4 racer spots to the starting grid

Road floor thickness is 2mm and total height of the parts is 12mm.
Lines are 1mm thick and deep on the track surface so cars won't feel it when passing on, while still being visible, optionally you can pour paint or something to color the fissures

Road is 120 mm wide between the barriers and with a little "kerb" that will add some action when turning at max performance.

V2.0 Changelog:

-Revamped snapping layout, now is completely reversible, this will make assembling and printing more easy.

-Turns, Straight "grid" and "start" are now reversible, same for the ramp modules.

-Added Diameter 3 and 4 Turns modules, Ramp and Bridge related pieces.

-Still towards maximum compatibility, I've also added 3 new compensation parts A, B and C that are 70mm long to let you mix old and new modules along the same build, maintaining the correct alignment of the joints.

V1.0 Changelog:

-Straight sections lenght corrected from 160 to 140mm.

-For above reason I decided to incude 20 and 40mm long compensation segments, to prevent previously pre-V1.0 printed parts compatibility issues.

-Two new "traps" to add further challenge to your races.

Enjoy playing with this in your home!

Possible to print without bottom layers to save time, 2/3 top layers is enough and don't go too cheap with infill, a 20-30% will be okay, 2 perimeters, test parts made at 0.15mm layers but you can further speed up :D
