1/14 Big Stationary Trommel/Screener Unit v2

1_14-Big-Trommel-Back-Side.jpg 1/14 Big Stationary Trommel/Screener Unit v2
1_14-Big-Trommel-Battery-Bay.jpg 1/14 Big Stationary Trommel/Screener Unit v2
1_14-Big-Trommel-Decking.jpg 1/14 Big Stationary Trommel/Screener Unit v2
1_14-Big-Trommel-Front-Side.jpg 1/14 Big Stationary Trommel/Screener Unit v2
1_14-Big-Trommel-Inside-Spiral.jpg 1/14 Big Stationary Trommel/Screener Unit v2
1_14-Big-Trommel-Inspection-Door.jpg 1/14 Big Stationary Trommel/Screener Unit v2
1_14-Big-Trommel-Top.jpg 1/14 Big Stationary Trommel/Screener Unit v2
Front-Dimensions.jpg 1/14 Big Stationary Trommel/Screener Unit v2
Side-Dimensions.jpg 1/14 Big Stationary Trommel/Screener Unit v2
Drum Rear Sidewall 5.stl 1/14 Big Stationary Trommel/Screener Unit v2
Drum Rear Sidewall 4.stl 1/14 Big Stationary Trommel/Screener Unit v2
Drum Sidewall 5.stl 1/14 Big Stationary Trommel/Screener Unit v2
Drum Sidewall 4.stl 1/14 Big Stationary Trommel/Screener Unit v2
Belt V1 TPE 75a.stl 1/14 Big Stationary Trommel/Screener Unit v2
End Wall Hole Template.stl 1/14 Big Stationary Trommel/Screener Unit v2
Drum End Wall 2 v2.stl 1/14 Big Stationary Trommel/Screener Unit v2
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 3.8/5 (3 votes)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
8 files (STL and ZIP) Close
  • 14 Big Trommel v2.zip
    • B.O.M..txt
    • Instructions v2/1.PNG
    • Instructions v2/10.PNG
    • Instructions v2/11.PNG
    • Instructions v2/12.JPG
    • Instructions v2/13.JPG
    • Instructions v2/14.JPG
    • Instructions v2/15.JPG
    • Instructions v2/16.JPG
    • Instructions v2/17.JPG
    • Instructions v2/18.JPG
    • Instructions v2/19.JPG
    • Instructions v2/2.PNG
    • Instructions v2/20.JPG
    • Instructions v2/21.JPG
    • Instructions v2/22.JPG
    • Instructions v2/23.JPG
    • Instructions v2/24.JPG
    • Instructions v2/25.JPG
    • Instructions v2/26.JPG
    • Instructions v2/27.JPG
    • Instructions v2/28.JPG
    • Instructions v2/29.JPG
    • Instructions v2/3.PNG
    • Instructions v2/30.JPG
    • Instructions v2/31.JPG
    • Instructions v2/32.JPG
    • Instructions v2/33.JPG
    • Instructions v2/34.JPG
    • Instructions v2/35.JPG
    • Instructions v2/36.JPG
    • Instructions v2/37.JPG
    • Instructions v2/4.PNG
    • Instructions v2/5.PNG
    • Instructions v2/6.PNG
    • Instructions v2/7.PNG
    • Instructions v2/8.PNG
    • Instructions v2/9.PNG
    • Rear Walls.JPG
    • Side Walls.JPG
    • Single Wall.JPG
    • STL's v2/Conveyor/Conveyor Rail 1 Half.stl
    • STL's v2/Conveyor/Conveyor Rail 1.stl
    • STL's v2/Conveyor/Conveyor Rail 2 .stl
    • STL's v2/Conveyor/Conveyor Rail 2 Half.stl
    • STL's v2/Conveyor/Drive Roller Half 1.stl
    • STL's v2/Conveyor/Drive Roller Half 2.stl
    • STL's v2/Conveyor/Drive Roller.stl
    • STL's v2/Conveyor/Guide 1.stl
    • STL's v2/Conveyor/Guide 2.stl
    • STL's v2/Conveyor/Guide 3.stl
    • STL's v2/Conveyor/Guide 4.stl
    • STL's v2/Conveyor/Idle Roller x5.stl
    • STL's v2/Conveyor/Rail Mount 2 Half 1.stl
    • STL's v2/Conveyor/Rail Mount 2 Half 2.stl
    • STL's v2/Conveyor/Rail Mount Half 1.stl
    • STL's v2/Conveyor/Rail Mount Half 2.stl
    • STL's v2/Conveyor/Self Aligning Idle Roller.stl
    • STL's v2/Conveyor/Tensioner Block x2.stl
    • STL's v2/Conveyor/Tensioner Housing M.stl
    • STL's v2/Conveyor/Tensioner Housing.stl
    • STL's v2/Decking/Deck 1 x4.stl
    • STL's v2/Decking/Deck 2 x4.stl
    • STL's v2/Decking/Deck End.stl
    • STL's v2/Decking/Deck Support 1 x9.stl
    • STL's v2/Decking/Deck Support 2 x3.stl
    • STL's v2/Decking/Deck Support 3.stl
    • STL's v2/Decking/Deck Support End.stl
    • STL's v2/Decking/End Hand Rail.stl
    • STL's v2/Decking/Hand Rail 1 x3.stl
    • STL's v2/Decking/Hand Rail 2 x3.stl
    • STL's v2/Decking/Hand Rail 3.stl
    • STL's v2/Decking/Hand Rail 4.stl
    • STL's v2/Decking/Lower Stairs x2.stl
    • STL's v2/Decking/Small Rail.stl
    • STL's v2/Decking/Stair Handrail 1 B x2.stl
    • STL's v2/Decking/Stair Handrail 1 x2.stl
    • STL's v2/Decking/Stair Handrail 2 B x2.stl
    • STL's v2/Decking/Stair Handrail 2 x2.stl
    • STL's v2/Decking/Upper Stairs x2.stl
    • STL's v2/Drum/06b Pinion Gear.stl
    • STL's v2/Drum/3 5 8mm Drums/06B Drum Sprocket.stl
    • STL's v2/Drum/3 5 8mm Drums/10mm Drum 1.stl
    • STL's v2/Drum/3 5 8mm Drums/10mm Drum 2.stl
    • STL's v2/Drum/3 5 8mm Drums/3mm Drum 1.stl
    • STL's v2/Drum/3 5 8mm Drums/3mm Drum 2.stl
    • STL's v2/Drum/3 5 8mm Drums/5mm Drum 1.stl
    • STL's v2/Drum/3 5 8mm Drums/5mm Drum 2.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Bearing Gantry x3.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Coupler.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum End.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Lock Ring 1.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Lock Ring 2.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Lock Ring 3.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Lock Ring 4.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Lock Ring 5.stl
    • STL's v2/Drum/3 5 8mm Drums/Drum Lock Ring 6.stl
    • STL's v2/Drum/3 5 8mm Drums/Pinch Ring Mount.stl
    • STL's v2/Drum/3 5 8mm Drums/Pinch Ring.stl
    • STL's v2/Drum/4 8 15mm Drums/15mm Drum 1 v2.3mf
    • STL's v2/Drum/4 8 15mm Drums/15mm Drum 1 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/15mm Drum 2 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/4mm Drum 1 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/4mm Drum 2 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/8mm Drum 1 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/8mm Drum 2 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/Drum Coupler 1 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/Drum Coupler 2 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/Drum Coupler 3 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/Drum Coupler 4 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/Drum Coupler 5 v2.stl
    • STL's v2/Drum/4 8 15mm Drums/Drum Coupler Main v2.stl
    • STL's v2/Drum/4 8 15mm Drums/Drum End v2.stl
    • STL's v2/Frame/Drum Walls/Drum Center Support x2.stl
    • STL's v2/Frame/Drum Walls/Drum End Wall 1.stl
    • STL's v2/Frame/Drum Walls/Drum End Wall 2.stl
    • STL's v2/Frame/Drum Walls/Drum Rear Sidewall 2.stl
    • STL's v2/Frame/Drum Walls/Drum Rear Sidewall 3.stl
    • STL's v2/Frame/Drum Walls/Drum Rear Sidewall 1.stl
    • STL's v2/Frame/Drum Walls/Drum Rear Sidewall 4.stl
    • STL's v2/Frame/Drum Walls/Drum Rear Sidewall 5.stl
    • STL's v2/Frame/Drum Walls/Drum Rear Sidewall 6.stl
    • STL's v2/Frame/Drum Walls/Drum Sidewall 1.stl
    • STL's v2/Frame/Drum Walls/Drum Sidewall 2.stl
    • STL's v2/Frame/Drum Walls/Drum Sidewall 3.stl
    • STL's v2/Frame/Drum Walls/Drum Sidewall 4.stl
    • STL's v2/Frame/Drum Walls/Drum Sidewall 5.stl
    • STL's v2/Frame/Drum Walls/Drum Sidewall 6.stl
    • STL's v2/Frame/Girders/Drum Motor Lock.stl
    • STL's v2/Frame/Girders/Drum Motor Mount 775.stl
    • STL's v2/Frame/Girders/Drum Motor Mount Planetary Motor.stl
    • STL's v2/Frame/Girders/Inside Girder 1.stl
    • STL's v2/Frame/Girders/Inside Girder 2.stl
    • STL's v2/Frame/Girders/Inside Girder 3 Bigger Motor.stl
    • STL's v2/Frame/Girders/Inside Girder 3 Planetary Motor.stl
    • STL's v2/Frame/Girders/Long Girder 1 2.stl
    • STL's v2/Frame/Girders/Long Girder 1.stl
    • STL's v2/Frame/Girders/Long Girder 2 2.stl
    • STL's v2/Frame/Girders/Long Girder 2.stl
    • STL's v2/Frame/Girders/Outside Girder 1.stl
    • STL's v2/Frame/Girders/Outside Girder 2.stl
    • STL's v2/Frame/Girders/Plate 1.stl
    • STL's v2/Frame/Girders/Plate 2.stl
    • STL's v2/Frame/Girders/Upper Girder x4.stl
    • STL's v2/Frame/Walls/Bottom Rear Wall.stl
    • STL's v2/Frame/Walls/Lower Back Wall 1.stl
    • STL's v2/Frame/Walls/Lower Back Wall 2.stl
    • STL's v2/Frame/Walls/Lower Back Wall 3.stl
    • STL's v2/Frame/Walls/Lower Back Wall 4.stl
    • STL's v2/Frame/Walls/Lower Front Wall x3.stl
    • STL's v2/Frame/Walls/Lower Rear Wall.stl
    • STL's v2/Frame/Walls/Lower Triangle Wall 2.stl
    • STL's v2/Frame/Walls/Lower Triangle Wall x3.stl
    • STL's v2/Frame/Walls/Lower Wall Filler.stl
    • STL's v2/Frame/Walls/Top Rear Wall.stl
    • STL's v2/Frame/Walls/Upper Back Wall 1.stl
    • STL's v2/Frame/Walls/Upper Back Wall 2.stl
    • STL's v2/Frame/Walls/Upper Back Wall 3.stl
    • STL's v2/Frame/Walls/Upper Back Wall 4.stl
    • STL's v2/Frame/Walls/Upper Front Wall x3.stl
    • STL's v2/Frame/Walls/Upper Rear Wall.stl
    • STL's v2/Frame/Walls/Upper Triangle Wall 2.stl
    • STL's v2/Frame/Walls/Upper Triangle Wall x3.stl
    • STL's v2/Frame/Walls/Upper Wall Filler.stl
    • STL's v2/Hopper/Base/Door Handle x3.stl
    • STL's v2/Hopper/Base/Front Door 1.stl
    • STL's v2/Hopper/Base/Front Door 2.stl
    • STL's v2/Hopper/Base/Hinge 1 x6.stl
    • STL's v2/Hopper/Base/Hinge 2 x6.stl
    • STL's v2/Hopper/Base/Hopper Base Rear Wall 2.stl
    • STL's v2/Hopper/Base/Hopper Base Rear Wall.stl
    • STL's v2/Hopper/Base/Hopper Base Wall 1.stl
    • STL's v2/Hopper/Base/Hopper Base Wall 2.stl
    • STL's v2/Hopper/Base/Hopper Base Wall 3.stl
    • STL's v2/Hopper/Base/Hopper Base Wall 4.stl
    • STL's v2/Hopper/Base/Hopper Front Wall.stl
    • STL's v2/Hopper/Base/Hopper Stay 1.stl
    • STL's v2/Hopper/Base/Hopper Stay 2.stl
    • STL's v2/Hopper/Base/Hopper Stay 3.stl
    • STL's v2/Hopper/Base/Hopper Stay 4.stl
    • STL's v2/Hopper/Base/Hopper Stay 5.stl
    • STL's v2/Hopper/Base/Rear Door.stl
    • STL's v2/Hopper/Middle/Hopper Inside Ramp 1 Half.stl
    • STL's v2/Hopper/Middle/Hopper Inside Ramp 1.stl
    • STL's v2/Hopper/Middle/Hopper Inside Ramp 2 Half.stl
    • STL's v2/Hopper/Middle/Hopper Inside Ramp 2.stl
    • STL's v2/Hopper/Middle/Upper Hopper Front 1.stl
    • STL's v2/Hopper/Middle/Upper Hopper Front 2.stl
    • STL's v2/Hopper/Middle/Upper Hopper Front.stl
    • STL's v2/Hopper/Middle/Upper Hopper Rear 1.stl
    • STL's v2/Hopper/Middle/Upper Hopper Rear 2.stl
    • STL's v2/Hopper/Middle/Upper Hopper Rear Half 1.stl
    • STL's v2/Hopper/Middle/Upper Hopper Rear Half 2.stl
    • STL's v2/Hopper/Top/Top Hopper 1.stl
    • STL's v2/Hopper/Top/Top Hopper 2.stl
    • STL's v2/Hopper/Top/Top Hopper 3.stl
    • STL's v2/Hopper/Top/Top Hopper 4.stl
    • STL's v2/Hopper/Top/Top Hopper 5.stl
    • STL's v2/Hopper/Top/Top Hopper 6.stl
    • STL's v2/Hopper/Top/Top Hopper 7.stl
    • STL's v2/Hopper/Top/Top Hopper 8.stl
  • Belt V1 TPE 75a.stl
  • Drum End Wall 2 v2.stl
  • Drum Rear Sidewall 4.stl
  • Drum Rear Sidewall 5.stl
  • Drum Sidewall 4.stl
  • Drum Sidewall 5.stl
  • End Wall Hole Template.stl

Learn more about the formats
Last update
Publication date
Design number 1796216
mbudz10

mbudz10

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

A 1/14 scale big trommel/screener unit. This can be printed with a 220 x 220x 250 printer or bigger. Dimensions are in the pictures.

The drum is chain and sprocket driven, mirroring the mechanics of a real trommel.
Each component of the drum, including the mesh screening, is accurately replicated to achieve a realistic appearance.
The drum rotates smoothly, driven by a miniature motor and ball bearings concealed within the structure.
Classification System:
The unit features multiple classification sections: 3mm, 4mm, 5mm, 8mm, 15mm mesh.
Material entering the trommel passes through these classifications, separating finer particles from larger ones.
Hopper Conveyor:
A massive hopper sits atop the unit, capable of holding a significant volume of material.
A cleated belt conveyor transports material from the hopper to the trommel drum.
The conveyor system is meticulously crafted, featuring accurate detailing and functionality.
Controls:
The miniature trommel/screener unit may incorporate control features, such as switches or knobs, allowing users to operate its functions manually.
Alternatively, it could be designed to be remotely controlled, providing an interactive experience.
Additional Features:
Attention to detail extends to the smallest components, including bolts, hinges, and handles, enhancing the overall realism of the model.
LED lights may be integrated to mimic the lighting found on actual trommel/screener units, adding to its visual appeal.
Customizable elements allow enthusiasts to personalize their unit with optional accessories or modifications.
Scale Accuracy:
The 1/14 scale ensures that every aspect of the trommel/screener unit closely resembles its full-sized counterpart, offering an immersive experience for hobbyists and collectors alike.
Overall, the 3D printed 1/14 scale big trommel/screener unit is a remarkable fusion of craftsmanship and engineering, capturing the essence of the original machine in a compact and meticulously detailed form.

UPDATE 12/14/2024
Ball Bearings added to base of drum
Drum Seal added so material does not make its way under conveyor
New Drum sizes
Added a larger Spiral to accommodate wet material

3D printing settings

.4 nozzle
.2 layer height
2mm walls
2mm top and bottom layers
40-60% infill
supports-yes

Categories

All categories β€Ί Various β€Ί Sports & outdoor / Education / Dioramas

Meta tags

Tags

Advertising

Would you like to support Cults?

You like Cults and you want to help us continue the adventure independently? Please note that we are a small team of 4 people, therefore it is very simple to support us to maintain the activity and create future developments. Here are 3 solutions accessible to all:

  • ADVERTISING: Disable your ad blocker.
  • DONATE: Make a donation via Ko-Fi Donate
  • WORD OF MOUTH: Invite your friends to come, discover the platform and the magnificent 3D files shared by the community!

Sharing and downloading on Cults3D guarantees that designs remain in makers community hands! And not in the hands of the 3D printing or software giants who own the competing platforms and exploit the designs for their own commercial interests.

Cults3D is an independent, self-financed site that is not accountable to any investor or brand. Almost all of the site’s revenues are paid back to the platform’s makers. The content published on the site serves only the interests of its authors and not those of 3D printer brands who also wish to control the 3D modeling market.
