ISO M10 x 16 and M10 x 20 Threaded Bolts

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 1.3k views
  • 6 likes
  • 141 downloads

3D model description

I made (in Blender) these bolts as gadgets to be shared during a meeting.

I gave each printed bolt screwed into a real (commercial) metal nut, perfectly mating each other.

More info here: http://bit.ly/XEztcr

The full video of the speech (in italian) is also here:

http://www.youtube.com/watch?&v=ZWLOIle8thM

The part of the video that shows my Huxley printing two bolts:

http://youtu.be/ZWLOIle8thM?t=36m16s

Printed in Silver PLA - nice! - from Reprapworld using my ReprapPro Huxley.

UPDATE (2013/08/01): Actually the printed bolts are M10x16. I forgot I reduced the dimension to speed up printing. So I uploaded also the M10x16 file.

UPDATE (2013/05/05): M10 nut added.

UPDATE (2013/05/05): Nut's hexagon dimensions updated (Thanks to Balthazar)

  • 3D file format: STL

Tags

Creator

Designs 42
Downloads 1.4k
Followers 14

I am a Mechanical Design Engineer currently living in Italia. My interests range from photography to technology. I am also interested in design, Free Software, and Linux.

License

CC BY SA
