Elegoo Saturn 3 Buildplate Holder

20230805_111353.jpg Elegoo Saturn 3 Buildplate Holder
20230805_111335.jpg Elegoo Saturn 3 Buildplate Holder
20230805_113016.jpg Elegoo Saturn 3 Buildplate Holder
Resin Plate Rest.stl Elegoo Saturn 3 Buildplate Holder
Advertising
Share
Add to
Make
?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
Licence CULTS - Private Use
Publication date 2023-08-05 at 16:41
Design number 1365124
3D design format
STL Folder details Close
  • Resin Plate Rest.stl

Learn more about the formats
3D model size X 26.6 × Y 184 × Z 168 mm
MeanManIndustries

MeanManIndustries

3D printer file info

3D model description

This file allows you to print a build plate holder so that after a print you can mount the build plate vertical over the vat, allowing the excess resin to drain from the plate back into the vat.

This helps reduce resin waste and cleanup. I found it difficult to accomplish this on the Saturn 3 since the build plate cannot be mounted vertically like in the Saturn 2.

This holder is installed on the side of the vat and does not interfere with the build plate or the lid when closed (see pictures). It does not require any additional hardware and is printable with minimal supports.

3D printing settings

This file was sliced in Prusa 2.6.0 at 0.2mm layer height and 40% infill. It was printed on an Ender 5 Plus using PETG.
