BCN3D MOVEO - A fully OpenSource 3D printed Robot Arm
:still():format(webp)/https://files.cults3d.com/uploaders/11417472/illustration-file/1469701655-32610-6170/IMG_7106_ok.jpg)
?
Creation quality:
4.9/5
(7 votevotes)
Evaluation of members on the printability, utility, level of detail, etc.
Your rating:
0/5
- 65.2k views
- 241 likes
- 2.9k downloads
- 0 comments
- 0 makes
Designer
3D model description
BCN3D Technologies keeps taking important steps in order to achieve his goal of bringing the digital manufacturing technology to everyone. In this occasion we are presenting the BCN3D Moveo, a robotic arm design from scratch and developed by our engineers in collaboration with the Departament d’Ensenyament from the Generalitat de Catalunya. Its structure is fully printed using additive manufacturing technologies and its electronics are controlled by the software Arduino. It has a Marlin based firmware developed for robot arms with steppers by Zortrax. The BCN3D Moveo has 5 axis.
Moveo, fully functional nowadays, has been born, as all the BCN3D Technologies products, with an open and educational wish.
https://www.youtube.com/watch?v=XSY0kieEL8A
As we have done with all our developed products, the BCN3D Moveo files will be available for everyone. Thanks to the platform Github, a website where users around the world share their designs, anyone will be able to obtain all the necessary information in order to assemble his own BCN3D Moveo at home.
Nevertheless, BCN3D will fee all the Moveo know how on our Github account, as we have been doing with all the BCN3D Technologies products. Thus, the users will be able to find the bill of material (BOM), where all the needed components for the assembling of the arm come detailed, as the CAD designs, so anyone will be able to modify the BCN3D Moveo design as they wish.
Furthermore, the Github users will find the STL files for the structure printing and the assembling, fine tuning and firmware upload manuals, which will be available both in English and Spanish.
Download the BCN3D Moveo CAD files, the STL files, the assembly and user manual and the Bill of Materials on our Github: https://github.com/BCN3D
Read the full article: https://www.bcn3dtechnologies.com/en/bcn3d-moveo-the-future-of-learning/
Thanks to this project motivated by the Departament d’Ensenyament and developed by BCN3D Technologies everyone will be able to fabricate their own robotic arm at home, no highly technical knowledge needed. Therefore, we encourage you to fabricate the BCN3D Moveo and share the results on the social networks using the hashtag #BCN3DMoveo .
3D printing settings
-
3D printer file information
- Design number: 6489
-
3D design format: STL Folder details Close
- 1M1.STL
- 1M2.STL
- 1M3.STL
- 2M1.STL
- 2M2H.STL
- 2M2M.STL
- 3M1.STL
- 3M2.STL
- 3M2C.STL
- 4M1.STL
- 4M2.STL
- 4M2C.STL
- Bottom_Plate.STL
- Box.STL
- Cilinder.STL
- Fan_Module.STL
- Gripper_Left.STL
- Gripper_Right.STL
- Idol_Gear.STL
- Pivot_Arm.STL
- Potes.STL
- Servo_Gear.STL
- Suport_Drivers.STL
- Tapa_2M1.STL
- Tapa_3M1.STL
- Tapa_4M1.STL
- Tapa_TBB.STL
- Top_Plate.STL
- Publication date: 2016-07-28 at 12:53
License
CC BY-SA - Attribution - Share alike
