8mm Bore Inner Ball Mounted Pillow Block Insert Bearing

Advertising
?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.


Licence CULTS - Private Use
Publication date 2023-05-15 at 16:02
Design number 1222005
3D design format
SLDASM, SLDPRT, STEP, and STL Folder details Close
  • a_ball_bearing_with_grab_screw_vertical.SLDPRT
  • a_ball_bearing_with_grab_screw_vertical_ballbearing.SLDPRT
  • ball_bearing_with_grab_screw_vertical_assembly.SLDASM
  • ball_bearing_with_grab_screw_vertical_assembly.STEP
  • ball_bearing_with_grab_screw_vertical_assembly.STL
  • parted - a_ball_bearing_with_grab_screw_vertical-2.STL
  • parted - a_ball_bearing_with_grab_screw_vertical_ballbearing-2.STL

Learn more about the formats

3D printer file info

3D model description

this is the 3D model for the 8mm Bore Inner Ball Mounted Pillow Block Insert Bearing, modeled using solidworks 2021.

the modeling done using Vernier Caliber with an accuracy of +-0.2 mm.

this file can be used as a ready-modelled part for your designed, and to be included directly in any design that require this holder.

the file of this component is available in the following formats:

Solidworks 2021
-STEP file
_STL file ( not intended to be 3D printed).

Type: KP08

Material: zinc alloy

Bore Diameter:8mm

Mounting Hole Diameter: 5 mm

Durable with high precision

Can withstand great weight

The 8mm Bore Inner Ball Mounted Pillow Block Insert Bearing KP08 comes with top set screws which makes the inner ring of the bearing fix on the shaft. It is very convenient to install. There is a certain self-aligning ability for the bearing, so it can be mounted on a general accuracy rack.

3D printing settings

This file is NOT intended to be 3D printed because it is an electronic component.

you can print it as a show-case part, then to color it to looks like the real component but it is NOT functional.

NOTE: this part has been modelled manually with Vernier Caliber so it has the accuracy of about +-0.2 mm
