Gothic Cathedral Window Shelf 2 Sizes Multi Piece Build

It's been a while since we modeled a 3d printable wall shelf, and we've been itching to do another Gothic print. This one is inspired by centuries-old stained glass cathedral windows, with a sprinkling of Celtic and Wiccan Three Moon designs.

Multiple Pieces for Easy build with No Supports
The shelf prints out in two pieces - the Back and the Face. The back is the base and shelves. You could print just this piece and have a nice shelf. The Face is the ornamental front of the shelf. It is only 1mm thick and is meant to be glued over the top of the shelf to give it that unique ornamental look. Being two pieces, you can print the face a different color for a more striking contrast. A deep blue or purple shelf base with a black face would look especially nice.

Multiple Sizes to Suit All Prints
The model also comes in two sizes, one for large print beds (400x400) and one for standard sizes (220x220 to 256x256). Be sure to print the one that suits your bed size, rather than scaling it down. The larger file comes with Nail Holes built into the back. The smaller shelf is unable to support the same robust nail holes, so it has loops to hang over nails. If you size the large down, or the small up, these nail holes/hangers won't work properly.

DIMENSIONS
The Large Cathedral Shelf measures:

X = 30.0cm (11.8in)
Y = 37.5cm (14.8in)
Z = 4.3cm (1.73in)

The smaller shelf, at 100% scale, measures:

X = 18.8cm (7.4in)
Y = 23.5cm (9.3in)
Z = 4.3cm (1.73in)

The smaller size is designed to fit on standard size printers, but not all standard sizes are equal. the Bambu P1P, P1S and X1C have a bed size of 256x256, with a max printing area of 235x235. This is what we've sized the "Small" shelf to fit on. If you have a "standard" 235x235 printer with a max build area of 220x220, such as the Ender 3 Pro, you'll want to resize the already Small shelf to about 93% scale on the X and Y. Do not scale the Z - leave it at 100%. Be sure to scale both the Back and Face STL files to match.

Most of all, have fun with it! At standard size, our Gothic Window Shelf is great for displaying your favorite crystals and other small knick-knacks. The larger version is big enough to hold basic cosmetics and toiletries, should your bathroom need a little Gothic spurcing!

Be sure to Follow GetPrinted3D on Cults3D for more unique 3D printable holiday designs.

• See All GP3D Creations on Cults3D

IMPORTANT: Unless otherwise noted, ALL GetPrinted3D designs are Copyright protected. When you purchase a file, you do NOT have the right to sell the file or printed model. Files may not be redistributed under any circumstances. The models are for personal and private use, and may not be sold commercially without the explicit written consent of GetPrinted3D.

You can obtain a Commercial Resell License to print and legally sell our designs (not the files!) here:

• Patreon.com/GetPrinted3D

Layer Height: 0.2
Walls: 3
Infill: 20% (for strength)
Speed: 60 (or as fast as your printer can reliably print)
Supports: No
Raft: No

If you have a smooth glass print bed or a textured PEI plate that delivers a fine bottom surface, we strongly recommend printing the Face upside down. For this reason, we've already positioned it upside down. If you prefer the top surface, rotate it 180 degrees on the Y.
