Stepper Motors 70's 4 cylinder Euro wagon car - multi-part - no supports - easy print

A noppo/chibi inspired semi-deformed ‘tooned’ model of a 70's hot 4's, 4 cyl Euro wagon, segmented into easy to print parts with free rolling wheels. The model requires multiple #4 x 3/8" pan head screws (or 4G x 9mm sheet metal screws), and two Chupa Chup plastic sticks for use as axles.

SAFETY WARNING: THIS MODEL IS NOT FOR YOUNGER CHILDREN - SMALLER PARTS MAY BREAK OFF AND BECOME A CHOKING HAZARD. THIS MODEL DOES NOT COMPLY WITH TOY SAFETY STANDARDS!!!!

● Easy to print parts - no supports required

● Designed with colour breaks. Print parts in different colours on single colour printers for a more interesting look.

● Requires multiple #4 x 3/8" pan head screws (or 4G x 9mm sheet metal screws), and two Chupa Chups sticks cut to 48mm for the axles

● In addition to the necessary screwdriver, and cutting blade for the Chupa Chup stick, having some small files can be helpful

The part orientation for printing as per upload is correct. Some parts require a small amount of bridging while printing, though they'll still print well enough without supports. Interconnecting part fit may be tight, depending on the plastics used, or the printer/slicer settings. The tolerances on the tyre/hub combo are important. The hub is intended to be a tight fit onto the Chupa Chup stick, and the tyre needs to also be a tight fit on the wheel. Printing and scaling one tyre/hub combo until the sizing is correct for the axle (before committing to the other wheels/tyres) is recommended. The taillights also benefit from being a snug fit into the bodyside pieces. Also worth noting is that the roof has a pair of modelled in snap-off supports, and that the tailgate is slightly problematic where the taillights fit it, as there's a small triangular tab of plastic that also needs to be manually removed. Some hand finishing to get the taillights fitting nicely really helps.

Multiple #4 x 3/8" or 4G x 9mm sheet metal screws are used to join parts throughout the model. All but two are hidden when the buggy is complete. Assembly of the model parts in the correct part order is necessary, though it is a bit of a puzzle that you will need to figure out yourself :) With correctly sized parts, no glue is necessary, allowing for part replacement if any should be required. Often the joining of the chassis assembly to the body assembly takes careful, yet firm pressing to get the parts to mate, which makes assembly less suited to younger builders.

Additionally, the parts body_side and mudguard need to be both mirrored and printed. A second mirrored taillight is also required.

Also included are a small selection of wheel styles to choose from, for a more personalised look.

This vehicle also uses the same #4 x 3/8" or 4G x 9mm pan head screw size featured across my other models, so if you have any left over from another build, here's a chance to use a few more of them up! And finally, if you like the model enough to print it, please consider taking a pic or two, and posting a make. I like those!

Note: Each grid square in the build pics are 1cm
