Salto H101 RC glider w/retractable EDF 50mm or Folding Prop

00.jpg Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
00a.jpg Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
01.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
02.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
03.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
04.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
05.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
07.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
08.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
09.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
10.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
11.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
retrEDF-2.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
retrEDF-1.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
Stand-01.png Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
16.jpg Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
01 canopy part 1 v4 LW 1224.stl Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
02 canopy part 2 v4 LW 1224.stl Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
001 stand 1 v2.stl Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
002 stand 2 v2.stl Salto H101 RC glider w/retractable EDF 50mm or Folding Prop
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
15 files (STL and ZIP) Close
  • 001 stand 1 v2.stl
  • 002 stand 2 v2.stl
  • 01 canopy part 1 v4 LW 1224.stl
  • 02 F1 F2.zip
    • 03 F1F2 one part (edf) PETG 2224.stl
    • 04 F1 tip v2 PETG 2224.stl
    • 05 F2 motor v2 PETG 244 10.stl
    • 06 battery bracket v2 PETG.stl
    • 06 battery bracket v3 PETG.stl
    • 07 battery bracket extention 1 PETG.stl
    • 07 battery bracket extention 2 PETG.stl
    • 08 F1F2 one part (glider) PETG 2224.stl
  • 02 canopy part 2 v4 LW 1224.stl
  • 03 F3 F4.zip
    • 10 F3 v3 LW 2224.stl
    • 11 F4 v3 LW 2224.stl
    • 12a hub L front gear PETG.stl
    • 12b hub R front gear PETG.stl
    • 13 tyre front gear TPU.stl
    • 14a spar center L v3 PETG.stl
    • 14b spar center R v3 PETG.stl
    • 14c spar center Top PETG.stl
    • 15 M4 t i fingerscrew 4x PETG.stl
    • 16a M4 pin front L PETG.stl
    • 16b M4 pin front R PETG.stl
    • 17a M4 pin rear L PETG.stl
    • 17b M4 pin rear R PETG.stl
    • 18 M4 pin wing 4x PETG.stl
  • 04 F5.zip
    • 21 F5 v2 LW 2224.stl
    • 22 edf door L v2 PETG.stl
    • 23 edf door R v2 PETG.stl
    • 24 F5 front frame (edf) PETG.stl
    • 25 F5 rear frame (tail) PETG.stl
    • 26 servo bracket X10 A12T PETG.stl
    • 27 F5 servo bracket L PETG.stl
    • 28 F5 servo bracket R PETG.stl
  • 05 F6 F7.zip
    • 30 F6 part 1 LW 1228.stl
    • 31 F6 part 2 LW1228.stl
    • 32 F6 front frame PETG 222 20.stl
    • 33 F6 tube 80 v3 PETG.stl
    • 34 F7 L PETG 1228.stl
    • 35 F7 R PETG 1228.stl
    • 36a hatch L PETG.stl
    • 36b hatch R PETG.stl
    • 37 hub rear wheel PETG.stl
    • 38 tyre rear wheel TPU.stl
    • 39 tail wheel PETG.stl
  • 06 Vtail R.zip
    • 41b Vtail stab 1 R LW 1228.stl
    • 42b Vtail stab 2 R LW 1228.stl
    • 43b Vtail ele 1 R LW 1228.stl
    • 44b Vtail ele 2 R LW 1228.stl
    • 45b Vtail tip R PETG 1224.stl
    • 46 Vtail tip 2x R L PETG 1224.stl
    • 47 Vtail servo cover L PETG.stl
    • 48 Vtail servo cover R PETG.stl
    • 49 Vtail ruder horn 4x PETG (template).stl
  • 07 wing v2 R.zip
    • 51b wing 1 R v2 LW 1228.stl
    • 52b wing 2 R v2 LW 1228.stl
    • 53b wing 3 R v2 LW 1228.stl
    • 54b wing 4 R v2 LW 1228.stl
    • 55b wing 5 R v2 LW 1228.stl
    • 56b wing 6 R v2 PETG 1228.stl
    • 57b wing 7 R v2 PETG 1228.stl
    • 58b wing 8 R tip v2 PETG 1228.stl
  • 08 flap v2 R.zip
    • 61b flap 1 R v2 LW 1228.stl
    • 62b flap 2 R v2 LW 1228.stl
    • 63b flap 3 R v2 LW 1228.stl
    • 64b flap 4 R v2 LW 1228.stl
    • 65 flap hing L v2 PETG.stl
    • 66 flap hing R v2 PETG.stl
    • 67 flap servo cover L PETG.stl
    • 68 flap servo cover R PETG.stl
    • 69 flap ruder horn 2x2 PETG (template).stl
  • 09 ail v2 R.zip
    • 71b ail 1 v2 R LW 1228.stl
    • 72b ail 2 v2 R LW 1228.stl
    • 73b ail 3 v2 R PETG 1228.stl
    • 74b ail 4 v2 R PETG 1228.stl
    • 75 ail 1 2 hing PETG x6.stl
    • 76 ail 3 hing PETG x6.stl
    • 77 ail servo cover L PETG.stl
    • 78 ail servo cover R PETG.stl
    • 79 ail ruder horn 4x2 PETG (template).stl
  • 10 retractable EDF.zip
    • 80 EDF bracket (FMS 50) PETG.stl
    • 81 EDF stop (FMS 50) PETG.stl
    • 82 nacelle unit (FMS 50) v2 PETG.stl
    • 83 nacelle stop PETG.stl
    • 84 bearing M PETG.stl
    • 85a bearing L PETG.stl
    • 85b bearing R PETG.stl
    • 86 push rod X10 PETG (template).stl
    • 87a outer lever v2 L PETG.stl
    • 87b outer lever v2 R PETG.stl
    • 88a inner lever L PETG.stl
    • 88b inner lever R PETG.stl
  • 11 stand.zip
    • 001 stand 1 v2.stl
    • 002 stand 2 v2.stl
    • 003 stand TPU stop.stl
    • 004 stand TPU CG stop.stl
    • 005 stand TPU CG stop v2.stl
  • building instructions.zip
    • 01 building instructions.pdf
    • 02 additional parts.pdf
    • 03 additonal parts retr EDF.pdf
    • 04 rc equipment.pdf
    • 05 settings.pdf

Learn more about the formats
Publication date
Design number 3649293
SigiRC

SigiRC

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

RC Glider Salto H101 1:6, wingspan 2552 mm, TOW 2100-2300 g, homage to the vintage WIK Salto out of the 70s, new 4flap-wing design with a modern JX airfoil (Vtail HT33)

all files included for 3 versions:
glider solo, glider with motor/prop, glider with retractable edf,
also included CG/ transportation stand

rc equipment:
6x HV servo 2xFlap/2xAil/2xVtail Ele Rud
1x HV servo retractable EDF (optional)
1x ESC minimal 50A, HV BEC
8CH receiver
4s Accu 3000mAh
no gyro

optional:
50mm EDF (FMS) or
outrunner motor (Dualsky) with folding Prop 10x6

a list of all additional parts and settings as well as building instructions are included in the download

under construction: 6s 64mm retractable EDF,
pendulum Vtail, "Hotliner" v3 wing

maiden and first flights
https://youtu.be/D2CZtmN02xU?si=s0jTz2DLepvhXvs0

"how to build and more" video under construction

don't hesitate to contact me via comment section of this design if you have any questions or problems

"a handsome glider for everyday", happy printing

3D printing settings

minimal print volume 220x220x250, for best results use a printer with core x/y, protoype was printed on kartesic (bed-mover) printer, due to the thin airfoil, the small flap, ail and elevator parts might have unprecise areas and need some post-processing

all parts printed in LW PLA (flow75) oder PETG HS,
each stl has a specific number and material/print recommendation

example: 01 canopy part1 v4 LW 1224 =
part No. 01, Version 4, printed with LW PLA (best results with colorFabb LW filament) and 1wall, 2top, 2bottom, 4%gyroid infill

all functional PETG HS parts normaly with flow 100, 222 20, or defined

!LW tolerances for vertical printing!

only R right stl's for wing, flap, ail and Vtail parts, mirror in your slicer
