[AAP01] RAPTOR PDW Conversion for AAP01

RAPTOR PDW AAP01 KIT

Disclaimer: Do not copy, modify or share any of these files. You're buying it for personal use only. Do not sell prints of this conversion or any parts of it for commercial use.

Here it is, the RAPTOR conversion that changes your AAP01 into PDW. It's not a replica of any actual firearm, but I tried to keep it minimalistic, realistic and durable. This conversions also got a buch of cool features:
- it's drop in (you only need to take off front iron sight from a stock AAP01),
- it has a ambidextrous, non-reciprocating charging handles on each side,
- it has a 1913 RIS full-lenght top rail, and also short 1913 RIS rail at the back (MCX style) to attach stocks like 5KU and other aftermarket RIS stocks,
- you can split the upper and lower of the AAP01 without taking off the conversion,
- you can change fire mode thru opening at the bottom,
- you can choose from 3 different handguard lenghts (longer ones require barrel extension),
- kit includes longer magazine baseplate, as well as M-LOK angled grip that holds spare magazine for your replica, and it's profiled to sit flush with the body,

Each part of the conversion is under 220x220x250mm, so you don't have to split the parts, just load and print. Also I tried my best to keep as much 45 degrees as possible, so they doesn't require a lot of supports - set your slicer to generate supports above 46* and you're good to go.

I printed it and fully tested. It's a fun and nice piece of kit. I recommend using ABS, ASA or stronger material to keep it sturdy and robust. You can use a little bit of fine sandpaper on the charging handle rails for them to work smoothly, you also have to remember to lubricate them (I just used gun oil, the same I'm using for replica internals).

To assemble, you will need:
- 4x M2.5x10mm,
- 4x M2.5x nut,
- 10x M3x8 countersink (or more for longer handguards),
- 6x M3 nut
- 4x M4x12mm
- 4x M4 slim nut

Optional for strenghtning stock RIS rail:
- 2x M5x10mm countersink,
- 2x M5 nut,

Optional for MLOK Mag Grip:
- 2x M5x10 countersink,
- 2x M5 MLOK nut.

Iron sights and stock are not a part of a kit. I'm currently working on a stock and it will be free download add-on for this kit and other replicas with RIS rail at the back of receiver.
To see assembly intructions, print setting and pro-tips or to take part in disscussion about this build & new things to come, visit my discord server link.

Changelog:
-16.04.2025
- changed picture,
- uploaded STL (not only the .zip),
- reuploaded .zip,
- uploaded updated mainbody,
- added 9 inch handguard (5 slot MLOK) and its top rail.

Disclaimer: Do not copy, modify or share any of these files. You're buying it for personal use only. Do not sell prints of this conversion or any parts of it.

I printed it with FDM Ender3 with some mods, using Creality HyperABS Black. Use ABS, ASA or stronger materials.
Print everything as it loads into the slicer. Yes, endbody prints RIS rail down-the-table. Set supports over 46 degree. Use support blocker for mag catch on magazine_grip. For more information visit discord server.
