Steeldart Score System (like Autodarts)

Creation quality: 4.8/5 (3 votes)
Evaluation of members on the printability, utility, level of detail, etc.

  • 1 comment

Licence CULTS - Private Use
Last update 2023-11-21 at 18:59
Publication date 2023-09-08 at 07:29
Design number 1437110
3D design format
PDF, RAR, and STL Folder details Close
  • Aukey_Kopf_PC_LM1E.stl
  • Fuss.stl
  • Fuss_40mm_länger.stl
  • Holzplatte CNC fräsen.rar
    • Autodarts.dxf
    • Holzplatte_CNC_Fraesen_PDF.pdf
    • TestBoard6ArmeRobbel90_1.JPEG
    • TestBoard6ArmeRobbel90_2.JPEG
    • Text..txt
  • Kamera_Deckel.stl
  • Kameradeckel_Aukey_PC_LM1E.stl
  • Kamerahalter.stl
  • Ring_Halter.stl
  • Ring_Teil.stl
  • Ring_Verbinder.stl
  • Schwinge_mit_LED_Bohrung.stl
  • Schwinge_ohne_LED_Bohrung.stl
  • Target_Corona_Adapter.stl
  • Zusammengefügt.pdf

Learn more about the formats

3D printer file info

3D model description

Youtube videos to help you:

If you don't have a 3D printer yourself, you can get the 3D printed parts with all the screws and fusible nuts directly from me. Just write me a PN in the Autodarts Discord.

I offer here my modular lighting ring for a Steeldart score system (such as Autodarts)

With this complete package of 3D print files you can print a complete lighting system for a Steeldarts score system.

Even if you already have a lighting system, these parts are suitable.

The systems of the manufacturers "Winmau Plasma" and "Target Corona" are supported.

A basic holder consists of base + rocker + camera holder + camera cover.

3 of these assembled basic holders are required.

The "Winma Plasma" LED ring can be mounted directly on these 3 base holders.

There is a STL file foot 40mm longer. This is for when you have a Vilyzer behind your board (Silentboard).

For Target Corona users, 3 more adapters are required.

These adapters consist of 2 parts each and can be found under "Target_Corona_Adapter"

These adapters can be used to attach the "Target Corona lighting ring" to the 3 basic holders.

If you do not yet have a lighting system, you can build your own lighting ring using the screw-on ring parts.

For this, 3x ring_holders 9x ring_parts 12x ring_connectors must be printed.

Exploded views for assembly are attached as PDF files.

You will also find the necessary screws and fusible nuts on the PDF drawings.

All STL files are already aligned as they should be printed.

What is new ?

  1. height of the light ring adjusted

  2. connections between the ring parts now opaque

  3. camera head and cover symmetrical table

  4. swing arm has a hole for 2 cables for the LED power supply (solder yourself)

5.ring_connector changed corona holder extended (no matter what you set up cameras always have the same position)

7.2xM4 foot to swing arm now centered

8.Exposions PDF created

Standard parts Target Corona:

Fusion nut M4 18x

Melt-in nut M2 18x

Cylinder head screw M4x14mm 18x

Cylinder head screw M2x6mm 12x

Cylinder head screw M2x4mm 6x

Standard parts Winmau Plasma:

Fusion nut M4 18x

Melt-in nut M2 12x

Cylinder head screw M4x14mm 12x

Cylinder head screw M4x10mm 6x

Cylinder head screw M2x6mm 6x

Cylinder head screw M2x4mm 6x

Standard parts complete ring:

Fusion nut M4 18x

M3 fusion nut 24x

Melt-in nut M2 12x

Cylinder head screw M4x14mm 12x

Cylinder head screw M4x10mm 6x

Cylinder head screw M3x10mm 24

Cylinder head screw M2x6mm 6x

Cylinder head screw M2x4mm 6x

Melt-in nuts left:

21.11.2023 DXF file for wooden base plate added (.rar)

06.01.2023 Camera heads Aukey PC-LM1E

->Camera heads for Aukey PC-LM1E added

->Remove the camera from the housing and drill out 2xD1.5 to D2.

-> Youtube video about this : coming on 07.11.2023

Many thanks to the Autodarts community who have contributed to this project with their many ideas and suggestions for improvement.

Special thanks to @Lee085 @Arnes-hoernertee

3D printing settings

Layer height 0.2mm

Support is only required for camera holder and camera swing arm.

All other parts are printable without support.
