20x20Alu Square Steeldarts Score System

Video links

https://www.youtube.com/watch?v=fg05KLHVSqY

https://youtu.be/mjzJyDZTQrk?si=pEa2IJZHKdvTk0-c

OnlineShopRobbel90

Link to OnlineShopRobbel90 --> link

**Youtube

Link to the Youtube Channel --> link

Facebook group:

Link to the Facebook group --> link

Discord:

Discord --> link

Camera Set:

Cameras --> link

If you don't have a 3D printer yourself, you could get the 3D printed parts with all the screws and fusible nuts directly from me. Write me a PN in the Autodarts Discord or directly via my profile. Join the Discord for questions under the following link: link.

I offer here my new, again fully modular and very stable Steeldarts Score System for self-printing.

Compatible with the following parts:

• DIY Robbel90 pressure ring

• Winmau Plasma

• Target Corona System

The height of the light ring can be flexibly adjusted by moving the middle section. This allows you to test different positions. I recommend a distance of 65mm between the bottom of the camera head and the top of the center section (this is the same height as the DIY Robbel90 ring)

You need 20×20mm aluminum square tube in 280 mm length. I ordered the square tubes directly to length. You can find my Liferant at the following link.

Aluminum square tube

• 3x - 20×20x2mm (This is what I used)

• or 3x - 20×20x1.5mm (function also 280mm long)

Each part must be printed 3x. I would recommend aligning the parts as shown in the pictures.

The following are also required:

• 6xM3 fusion nut M3x5.7mm

• 6xM3 grub screw M3x6mm --> Cylinder head screw also works but then you can see the screw head protruding.

• 15xM2 M2x4mm fusion nut

• 15xM2 Cylinder head screw M2x6mm

Target Corona adapter:

6 x M4 x 16mm cylinder head screws

6 x M2 fusion nuts

6 x M2 x 6mm cylinder head screws

Mission Torus 270 adapter:

6 x M4 x 16mm cylinder head screws

6 x M2 fusion nuts

6 x M2 x 6mm cylinder head screws

Clamp base and center section with M3 fusible nut + M3x6mm or M3x8mm grub screw.

Clamp camera head with M2 fusion nut with M2x6mm cylinder head screw.

The parts are simply plugged together and then each secured with a screw.

Align the parts as shown in the pictures.

I printed with the Bambulab X1C and P1S with 0.2mm layer height
