RECTANGULAR GRAPHICS CARD HOLDER

RECTANGULAR GRAPHIC CARD SUPPORT (6 to 8 cm and 8 to 10cm), to future updates, I will be uploading more or less sizes, if you want any specific size you can contact me or comment.

Minimalist, free of names or brands.

8cm: (6-8cm)

Optimal maximum height to reach: 10CM

Minimum height : 6cm

10cm: (8-10cm)

Optimal maximum height at which it reaches: 10CM

Minimum height : 8cm

NO BRACKETS REQUIRED

NO SUPPORTS

it prints horizontally (except for the bolt), don't worry about brackets it doesn't need, but it does use jumpers (so make sure they are set correctly)

these are the parameters that I used (you can modify them)

Layer height: 0.28 (that's the maximum I recommend) (0.32 works great too)

Walls: 2 or 3

Layers Sup/Inf: 3 or 4 upper to make the upper part look very good, the lower one is fine with 2

Filling: 10% (Lines- Zig Zag pattern or whatever you like)

Filling Speed: 50mm/s, (100 goes great)

Outer Wall Speed: 35mm/s (40 or 100 works great)

Inner Wall Speed: 50mm/s (100 goes great)

Initial Layer Speed: 20 or 15 mm/s (50 or 40 also works fine for me)

Adhesion : Edge 5 lines or not, it depends on how is your adhesion.

[HORIZONTAL EXPANSION: -0.085 mm] - you can use it or not, if your printer is well calibrated with exact measurements (the model already has tolerance so if your printer is well calibrated with exact measurements you will have no problems).
