Respooler

After the release of the bambulab x1c carbon i needed a way to respool 5kg rolls to 1kg in order to save money and use them in the ams, so i designed a respooler that automaticly does the job, you just set it and forget.It has a scale in it to tell it to stop when it gets to 1kg and guides the wire on evenly unlike using a drill.

The zip file includes everything you will need to construct it including extensive guides for the wiring, assembly, parts list with links to buy the parts and ready to go code, which will make it a breeze to assemble even for beginners, the coding has already been done for you its just a matter of following the guide to load it on.
It comes with a stl for esun spools but more will be added.

Edit:The respooler will slow down when it gets close to 1kg progressively to stop birds nests,all versions of the code have this feature turned on.
If you want the code customized for different applications leave a comment below or otherwise i can help point you in the right direction on what to change.

edit:
-Changed bearing mount because it had holes that were different sizes.
-The parts labelled v2 use bolts instead of the dowel in the legs to locate. You need to change all parts that have a v2 for this to align up.
-please use wiring schematic v2 to connect your circuit.

The bambulab spool addon link below.

https://cults3d.com/en/3d-model/tool/respooler-bambulab-filament-addon

20% infill on all parts except the spool holder which is 100%infill.
.2mm layer height and supports turned on,the speed will be depended on the printer you use.
You need a print bed size of 200x200x150 minimum.
