CamTilt Mini Camera Tilt Head

A simple camera tilt head for use in timelapse and panning video production. The small size of this tilt head is appropriate for small cameras and phones.

The head is particularly useful on a panning platform such as the Syrp Genie Mini where you need to tilt the camera but at the same time need to keep the camera level. Thus making a tilt head more desirable than a ball head.
A bubble level allows easy leveling of the panning platform. A version without the level is included.

The adapter socket accomodates the common Manfrotto 200PL plate slid in from the side and secured with a lock knob. If you need you can 3D print hits as well

Required parts:
3 #4-40 threaded inserts
3 #8-32 threaded inserts
1 1/4"-20 threaded insert
3 #4-40 1/2" flat head machine screw
1 #8-32 2" socket head machine screw
1 #8-32 1-1/2" socket head machine screw
1 #8-32 1/2" socket head machine screw with knob
1 1/2" or 12.5mm bubble level (optional)

• Use a fine detail nozzle 0.4mm or smaller
• Support should be used, touch buildplate only
• suggest use of a higher temperature material such as ABS to avoid distortion if you leave this in a hot car
• Note that all threaded inserts are installed on the opposite side from the mating screw for maximum strength.
