Arduino 5.0 Robotic Arm (STL Files) - Save, Play, Export and Import Motions

Advertising
Download US$ 11.71+
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
38 files (RAR and STL) Close
  • Arm part for servos.stl
  • Arm part for shafts.stl
  • BrazoRobotico5.0_arduino_code.rar
  • Fixed base.stl
  • Forearm for servo.stl
  • Forearm part for shaft.stl
  • Forearm rotation joint_1.stl
  • Forearm rotation joint_2.stl
  • Forearm–Arm joint_1.stl
  • Forearm–Arm joint_2.stl
  • Forearm–Arm joint_3.stl
  • Forearm–Arm joint_4.stl
  • Forearm–Arm joint_5.stl
  • Gripper cover.stl
  • Gripper finger_1.stl
  • Gripper finger_2.stl
  • Gripper gear.stl
  • Gripper joint (servo).stl
  • Gripper joint (shaft).stl
  • Gripper joint connector.stl
  • Gripper rack and shaft housing.stl
  • Gripper servo housing (rotary part).stl
  • Gripper shaft support.stl
  • ROBOTIC ARM CONTROL FABRI CREATOR.rar
  • Rack gear housing.stl
  • Rack gear_1.stl
  • Rack gear_2.stl
  • Rotary Body of the Gripper.stl
  • Rotating base adapter for servo1.stl
  • Rotating base adapter for servo2.stl
  • Rotating base central cover.stl
  • Rotating base.stl
  • Servo mount for gripper rotation.stl
  • Support Leg_1.stl
  • Support Leg_2.stl
  • Support Leg_3.stl
  • Support Leg_4.stl
  • Support Leg_5.stl

Learn more about the formats
Publication date
Design number 3283130
FABRI_CREATOR

FABRI_CREATOR

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

Aviso importante: Este producto de Cults3d incluye TODOS los archivos Stl necesarios para imprimir, el código para Arduino y la Aplicación de control del brazo robótico compatible para Windows y Linux. En resumen, todos los archivos DIGÍTALES para armar tu propio Brazo Robótico🥳
Si ya compraste este producto de Cults3D puedes adquirir este kit con los tornillos, componentes y herramientas necesarias para armar el brazo (NO INCLUYE ARCHIVOS DIGITALES): https://fabricreator.com/products/kit-brazo-robotico-5-0-fabri-creator?variant=47069075898606

Encuentra aquí todos los componentes físicos, herramientas y archivos digitales necesarios para ensamblar (no se requiere soldar ni cortar cables), controlar y programar tu brazo con precisión y compatibilidad total con Arduino😊: https://fabricreator.com/products/kit-brazo-robotico-5-0-fabri-creator?variant=47068931981550

Tutorial del proyecto completo:
https://youtu.be/mH10h8SrDmM?si=UG6NzNVuVZEX_mjJ

Lista de componentes eléctricos y electrónicos:
8 × Servomotores TD-8120MG 180°
1 × Servo Shield PCA9685 I2C – 16 canales
1 × Arduino UNO
1 × Fuente de alimentación ajustable 3–12 V 10 A
1 × Cable USB para Arduino UNO (100 cm)
1 × Cable con puerto Jack DC 5.5 × 2.1 mm (10 cm)
Accesorios:
2 × Servo Extension Cable 30 cm
2 × Servo Extension Cable 50 cm
1 × Servo Extension Cable 10 cm
8 × Aluminium Servo Horn/Arm 25T redondos
Herramientas:
1 × ESD-13 Clamp (pinza de sujeción de precisión)
1 × Llave Allen 2.5 mm
1 × Llave Allen 3 mm
1 × Destornillador de cabeza plana (2,0 mm)
1 × Destornillador Phillips (2,0 mm)
Tornillería:
35 × Tornillos M3 × 8 mm cabeza Allen
5 × Tornillos autorroscantes M3 × 6 mm
10 ×Tornillos autorroscantes M4 × 8 mm
70 × Tornillos autorroscantes M4 × 12 mm

3D printing settings

Relleno de impresión 9%
Paredes de impresión: 3
Soporte recomendado: Tipo Árbol

Categories

All categories › Gadget › Electronics / Robots

Meta tags

Tags
