Panther Ausf. G Engine Details [Modular Master Set] FM25-039

FM25-039 Panther Ausf. G – Engine Details (Modular Master Set)
Scale: 1/35

High-quality digital scale model detail set.
3D printable STL files for SLA printers.

BASED ON 3D SCANS AND ORIGINAL TECHNICAL REFERENCES

---

► THE ULTIMATE PANTHER AUSF. G ENGINE DECK UPGRADE — MODULAR MASTER SET

If you want a guaranteed upgrade for your Panther’s engine deck, this is it.
No compromises. No guesswork. No “almost fits”.

This Modular Master Set replaces weak kit parts with scan-level, print-ready engine
deck details — engineered as a complete system with correct variants and clean assembly.

Get a Guaranteed Upgrade — Print Unlimited.
Print. Clean. Install. Done.

► WHY THIS SET EXISTS

Most engine deck “upgrades” fail in three ways:

• the mesh looks toy-like (or too thick)
• parts don’t match each other (mixed styles / wrong variants)
• you lose hours fitting, sanding, and improvising

This set was designed to eliminate all three.
Every part is:

• based on real 3D scans + original technical references
• tuned specifically for 1/35 proportions and print reality
• tested for clean results on calibrated SLA/MSLA printers
• organized as a modular system — not a random part dump

You’re not buying files.
You’re buying certainty.

► WHAT YOU ACTUALLY SAVE

• Hours of research
• Multiple aftermarket purchases
• Trial-and-error fitting
• Support setup frustration

► WHAT YOU ACTUALLY GET (THE “FEAR REMOVAL” PART)

You don’t need to be a printer wizard. You get two paths:

A) EASY-USE (fast, safe, still detailed)
Pre-built parts designed to save time and reduce mistakes.

B) MODULAR (maximum control)
Separate mesh / covers / variants so you can build the exact configuration you want.

Same quality. Different workflow.

► BUILT FOR SERIOUS MODELERS

This set is for builders who:

• value accuracy
• want clean assembly
• care about correctness
• don’t want to fight their printer

Supported files are ready to go.
Unsupported files give full control.

You decide.
The quality stays the same.

► ONE SET. ALL OPTIONS.

This set covers multiple engine deck configurations in one unified system, including:

• Early–mid Panther G layouts
• Late Panther G layouts (including heater shutter options)
• Jagdpanther G2-specific features
• Multiple mesh / cover states (open → partial → closed)
• Cooling fans with correct structure + mesh options
• Antenna bases + small engine deck fittings

Instead of choosing one configuration, you get all of them.

► BOTTOM LINE

If you’re building a Panther Ausf. G and you want:

• maximum realism
• minimum frustration
• a clean, professional engine deck result

This is the Master Set.

Not cheaper.
Not simpler.
Just better.

---

SHORT DESCRIPTION:

This set provides a comprehensive, modular engine deck upgrade for the Panther Ausf. G
in 1/35 scale.
All parts are designed for maximum accuracy, clean assembly, and compatibility with
common Panther kits.

You get both Modular and Easy-Use workflows, plus supported files for reliable printing.
Engine deck variants for Panther G early–mid, late configurations, and Jagdpanther G2
are included.

Designed for experienced modelers — but structured to be beginner-safe with the
Easy-Use + supported path.

Designed for experienced modelers and properly calibrated SLA printers.

---

INCLUDED CONTENT:

► Supported Files

• Pre-supported, print-ready assemblies for reliable SLA printing
• Optimized support layout for minimal cleanup + dimensional accuracy

Includes supported assemblies such as:
• Cooler cover variants (Panther G Type A / Type B / Jagdpanther G2)
• Compartment heater variants (Easy-Use)
• Cooling grid base + grid states (open / slightly closed / closed)
• Antenna bases / engine deck detail assemblies (supported)

► Unsupported Files

• Individual parts for custom orientation and user-defined support setups
• Modular components grouped by function and variant

► INCLUDED PARTS – PART LIST (UNSUPPORTED / MODULAR + EASY-USE)

General / Small Details
G1 Panther Ausf. G 2m Antenna Base
G2 2m Antenna (Panther G)
H1 Engine Hatch Stop A
H2 Engine Hatch Stop B
H3 Large Lifting Hook (engine deck)
H4 Small Lifting Hook (engine deck)
H5 Armor Cap for Air Intake (Panther G v3)
H6 Air Intake Hole (removed cross grid)
H7 Air Intake Hole (screened flange)

MODULAR (1.1 modular)
A1 Main Cooling Fan – Panther G Type A
A2 Main Cooling Fan – Panther G Type B
A3 Main Cooling Fan – Right (Jagdpanther G2)
A4 Main Cooling Fan Mesh
B1 Fighting Compartment Heater v2
B2 Fighting Compartment Heater Mesh
B3 Heater Mesh – Partially Closed
B4 Heater Mesh – Closed
B5 Heater Covers Type A
B6 Heater Covers Type A – Half Closed
B7 Heater Covers Type B
B8 Heater Covers Type B – Half Closed
B9 Closed Heater Covers – Empty Holder
C1 Cooling Grid Base (Panther G)
C2 Cooling Grid Early–Mid Mesh
C3 Armored Mesh – Open
C4 Armored Mesh – Slightly Closed
C5 Armored Mesh – Closed

EASY-USE (1.2 quick use)
D1 Main Cooling Fan Type B (L) – Quick-Use
D2 Main Cooling Fan Type B (R) – Quick-Use
D3 Main Cooling Fan Type A (L) – Quick-Use
D4 Main Cooling Fan Type A (R) – Quick-Use
D5 Main Cooling Fan Jagdpanther G2 (R) – Quick-Use
E1 Compartment Heater Type A (open) – Quick-Use
E2 Compartment Heater Type A (partially closed) – Quick-Use
E3 Compartment Heater Type A&B (closed) – Quick-Use
E4 Compartment Heater Type B (open) – Quick-Use
E5 Compartment Heater Type B (partially closed) – Quick-Use
F1 Cooling Grid Early-Mid (late only left side) – Quick-Use
F2 Cooling Grid Late Heater Shutters (open) – Quick-Use
F3 Cooling Grid Late Heater Shutters (partially closed) – Quick-Use
F4 Cooling Grid Late Heater Shutters (closed) – Quick-Use

(All files are organized in clearly labeled folders: supported / unsupported, modular / easy-use.)

---

COMPATIBILITY:

Fits all common Panther Ausf. G kits, including:
• Das Werk
• Takom
• Border Model
• Other compatible Panther Ausf. G kits

Minor adaptation may be required depending on manufacturer tolerances.

---

LICENSE INFORMATION:

These files are licensed for personal, non-commercial use only.

NOT PERMITTED:
• Sharing or redistribution of the files
• Reselling or gifting of digital files
• Selling physical prints
• Resin casting or any form of reproduction

These files may be used for personal, non-commercial projects only.
Sharing, distributing, or reselling the files is not permitted in any form (digital or physical).
This also includes distribution/sale of 3D prints and any reproduction methods such as resin casting.

For commercial licensing options, please contact me.

Copyright Faustus Models
by Tom Theunissen
© Faustus Models 2026

---

Copyright © Faustus Models 2026
by Tom Theunissen
All rights reserved

3D PRINT INFORMATION:

► Baseline Printing Specs (reference values)

Layer Height: 0.02–0.04 mm

Normal Exposure: ~2.2–2.8 s

Bottom Exposure: ~30–40 s

Anti-Aliasing: Off

Resin: Standard grey or similar opaque resin recommended

(Reference printer: MSLA class – results may vary depending on printer, resin,
and calibration)

► Important Printing Notes

• SLA printing is not plug-and-play.
• Dimensional accuracy depends heavily on:
– Printer calibration
– Resin shrinkage
– Exposure tuning
• Transparent / clear resins require significantly lower exposure times.
Using standard exposure settings with clear resin may cause:
– Closed pin holes
– Oversized snap features
– Loss of functional tolerances

Unsupported files are recommended for advanced users who want full control over
orientation and supports.

---

POST-PROCESSING & HANDLING:

• Remove supports carefully using flush cutters or a sharp hobby knife
• Gently heat supports if required (warm water or hairdryer – low heat)
• Clean parts thoroughly and post-cure properly
• Light sanding or minor cleanup may be required
• Prime with standard modeling primers before painting
