Birthday Card

20231008_203647_1_1.gif Birthday Card
20231008_121747.jpg Birthday Card
20231008_203507.jpg Birthday Card
Screenshot-2023-10-07-113533.png Birthday Card
Card Base.stl Birthday Card
Card Text Front.stl Birthday Card
Card Text Middle.stl Birthday Card
20231008_203647_1_1.gif Birthday Card
20231008_121747.jpg Birthday Card
20231008_203507.jpg Birthday Card
Screenshot-2023-10-07-113533.png Birthday Card
Card Base.stl Birthday Card
Card Text Front.stl Birthday Card
Card Text Middle.stl Birthday Card
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
πŸ†Β BestΒ ?
License
3D design format
4 files (3MF and STL) Close
  • Birthday Card.3mf 200.0 Γ— 150.0 Γ— 1.0 mm
  • Card Base.stl 200.0 Γ— 150.0 Γ— 1.0 mm
  • Card Text Front.stl 69.543105 Γ— 127.399971 Γ— 0.32 mm
  • Card Text Middle.stl 86.74748600000001 Γ— 36.342396 Γ— 0.31999999999999995 mm

Learn more about the formats
Publication date
Design number 1506449
Design author NRDaeger
NRDaeger

NRDaeger

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

I 3D modeled this foldable birthday card to be a unique 3D printed gift for friends and family.

This card is comprised of 3 objects that can be printed in different colors. The card base has grooves down the center of the card allowing the card to be opened and closed like a typical paper card.

I recommend printing with a 0.4mm nozzle with slower printing speeds to improve small text detail. The quality of the front text and images on the card also depends greatly on good bed adhesion. Make sure the bed is prepped appropriately.

Card folding groove was designed to be printed at 0.16mm.

3D printing settings

Nozzle Size: 0.4mm
Layer Height: 0.16mm
Material: Bambu Lab PLA
Machine: Bambu Lab X1C
Speed (First Layer): 30mm/s
Speed (First Layer Infill): 80mm/s
Speed (Outer Wall): 150mm/s
Speed (Inner Wall): 250mm/s
Speed (Sparse Infill): 300mm/s
Speed (Internal Solid Infill): 250mm/s
Speed (Top Surface): 155mm/s
Print Surface: PEI
Bed Temp: 60C

Approx size: 150mm x 200mm x 1mm (unfolded)
Approx weight: 38g
