G1 Transformers Hound - No Support

Advertising
Share
Add to
Make
?
Creation quality: 5/5 (7 votes)
Evaluation of members on the printability, utility, level of detail, etc.
πŸ†Β BestΒ ?
License
3D design format
37 files (STL and ZIP) Close
  • 10_Hound_Body6_ShoulderJoint_BLACK.stl 40.38668800000002 Γ— 7.3456220000000005 Γ— 7.098174999999998 mm
  • 11_Hound_Hand1_Shoulder_BLACK.stl 28.085784999999987 Γ— 11.999995000000002 Γ— 11.778335999999996 mm
  • 12_Hound_Hand2_Bisep_BLACK.stl 19.948746 Γ— 14.572362000000002 Γ— 9.298157000000003 mm
  • 13_Hound_Hand3_Forehand_GREEN.stl 28.42688000000001 Γ— 25.253401 Γ— 11.740615999999989 mm
  • 14_Hound_Hand4_Ring_YELLOW.stl 54.42607100000001 Γ— 14.996827999999999 Γ— 3.0061489999999935 mm
  • 15_Hound_Hand5_Fist_BLACK.stl 25.174653000000006 Γ— 17.560154000000004 Γ— 11.74691 mm
  • 15_Hound_Hand5_Pointed_BLACK.stl 26.705763999999988 Γ— 27.291884999999997 Γ— 11.641311000000002 mm
  • 15_Hound_Hand5_Relax_BLACK.stl 26.069793000000004 Γ— 23.216683 Γ— 11.639999999999986 mm
  • 15_Hound_Hand5_Salute_BLACK.stl 17.901747999999998 Γ— 26.035519 Γ— 11.639571999999987 mm
  • 16_Hound_Waist1_Main_BLACK.stl 38.69584599999999 Γ— 21.625743999999997 Γ— 16.44276500000001 mm
  • 17_Hound_Waist2_Side_BLACK.stl 19.232909999999976 Γ— 10.0 Γ— 11.730682000000002 mm
  • 18_Hound_Waist3_Front_BLACK.stl 34.47758400000001 Γ— 26.769168999999998 Γ— 17.72564699999998 mm
  • 19_Hound_Waist4_Front2_YELLOW.stl 34.462233999999995 Γ— 6.484656999999999 Γ— 3.0314030000000116 mm
  • 1_Hound_Head1_Helmet_GREEN.stl 15.199982000000006 Γ— 18.303255 Γ— 16.30259699999999 mm
  • 20_Hound_Waist_Front3_GREEN.stl 11.612975999999975 Γ— 5.725795999999999 Γ— 6.414000999999985 mm
  • 21_Hound_Waist6_Hip_BLACK.stl 25.347137000000004 Γ— 13.301296999999998 Γ— 7.5000160000000164 mm
  • 22_Hound_Leg1_Thigh_WHITE.stl 31.973832000000016 Γ— 14.278979999999999 Γ— 27.534661 mm
  • 23_Hound_Leg2_KneeJoint_WHITE.stl 17.93133500000002 Γ— 18.371862 Γ— 10.080872 mm
  • 24_Hound_Leg3_Shin_GREEN.stl 36.21016 Γ— 18.414645 Γ— 41.16731300000001 mm
  • 25_Hound_Leg4_Ankle_BLACK.stl 11.0 Γ— 23.999596 Γ— 3.5000909999999976 mm
  • 26_Hound_Leg5_AnkleJoint_GREEN.stl 15.155272999999994 Γ— 15.479456 Γ— 5.682427000000004 mm
  • 27_Hound_Leg6_Foot_GREEN.stl 41.56648200000001 Γ— 28.097052 Γ— 14.284751999999997 mm
  • 28_Hound_Leg7_FootFront_BLACK.stl 29.577607 Γ— 3.5 Γ— 2.5982970000000023 mm
  • 29_Hound_Backpack1_GREEN.stl 32.99998399999998 Γ— 15.385862 Γ— 4.900008999999983 mm
  • 2_Hound_Head2_Face_WHITE.stl 9.011413000000005 Γ— 6.576838 Γ— 9.209732000000002 mm
  • 30_Hound_Backpack1_LIGHTBLUE.stl 29.39999400000002 Γ— 12.585861999999999 Γ— 1.1999969999999962 mm
  • 31_Hound_Gun_GREY.stl 53.56909900000001 Γ— 39.332792 Γ— 5.298339999999996 mm
  • 32_Hound_Shouldercannon1_GREEN.stl 12.016388000000006 Γ— 28.482841 Γ— 22.000045999999998 mm
  • 32_Hound_Shouldercannon2_GREY.stl 7.997527999999988 Γ— 8.0 Γ— 55.955794999999995 mm
  • 3_Hound_Head3_Eyes_LIGHTBLUE.stl 6.888076000000012 Γ— 3.7143299999999986 Γ— 2.464950999999985 mm
  • 4_Hound_Head4_Neck_GREY.stl 7.946166999999974 Γ— 13.753872999999999 Γ— 6.984451000000007 mm
  • 5_Hound_Body1_Main_GREEN.stl 46.0 Γ— 26.999999 Γ— 35.59999100000002 mm
  • 6_Hound_Body2_Side_WHITE.stl 12.300004000000001 Γ— 5.0 Γ— 12.897048999999981 mm
  • 7_Hound_Body3_Headlight_WHITE.stl 12.560868 Γ— 5.399999999999999 Γ— 3.6000060000000076 mm
  • 8_Hound_Body4_Front_WHITE.stl 15.200011999999987 Γ— 5.0 Γ— 11.522383999999988 mm
  • 9_Hound_Body5_Abdomen_WHITE.stl 23.0 Γ— 13.686385 Γ— 18.263869999999997 mm
  • Hound_Instruction.zip

Learn more about the formats
Last update
Publication date
Design number 170432
Design author Toymakr3D
Toymakr3D

Toymakr3D

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

G1 Transformers Hound from 1984 Transformers TV series, fully articulated model but not transformable.

DISCLAIMER:
1. Contains small parts and requires high precision. Your printer may need to be properly calibrated for best results.
2. This model is for fan art purposes only. The original Transformers characters are the property of Hasbro/Takara Tomy. The creator is in no way associated with the owners.

Scale: 1:30 (14cm)
Coloring can be done by using different color of filament (detail on files name)
No Support
Gap tolerance: 0mm balljoint, 0.05mm swivel, 0.15 peg joint
Best print orientation for maximum strength result
Easy to print
Easy to assemble
Easy to rescale
More updates: https://www.instagram.com/toymakr3d/

Point of articulation:
1. Neck ball joint
2. Abdomen ball joint
3. Shoulders ball joint
4. Upper arm swivel joint
5. Elbow ball joint
6. Wrist swivel
7. Waist swivel
8. Hip ball joint
9. Thigh swivel joint
10. Knee ball joint
11. Ankle ball joint

Accesories :
- Gun
- Shoulder Cannon

IMPORTANT TIPS:
- Use Nail Polish to fix loose ball joint
- Cutter or sand paper for tolerance adjustment
- Use super glue for split parts

3D printing settings

Nozzle: 0.4mm
Layer: 0.15mm (0.1mm for the head)
Filamen: PLA
Temperature: 190-200Β°C
Speed: 40/s
Skin/top/bottom: 0.8mm
Infill: 25%
