F9F-8B Cougar RC 70mm EDF V2

Advertising
Share
Add to
Make
?
Creation quality: 5/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
34 files (STL and ZIP) Close
  • Aileron_1.stl 124.90258 Γ— 124.556454 Γ— 107.226784 mm
  • Aileron_2.stl 118.41097200000002 Γ— 117.98341400000001 Γ— 100.442245 mm
  • Battery tray.stl 97.551422 Γ— 19.862792000000013 Γ— 205.35083 mm
  • Canopy transparent.stl 63.835823000000005 Γ— 105.01955799999999 Γ— 167.479645 mm
  • Canopy vac.stl 177.174629 Γ— 177.174699 Γ— 47.443863 mm
  • Canopy.stl 180.89982600000002 Γ— 192.043915 Γ— 118.9104 mm
  • Cockpit.stl 165.480187 Γ— 165.480278 Γ— 34.555779 mm
  • Drop tank.stl 171.606179 Γ— 172.838356 Γ— 195.979736 mm
  • EDF hatch.stl 101.98853299999999 Γ— 148.691383 Γ— 102.417114 mm
  • Elevator.stl 124.098404 Γ— 124.080055 Γ— 179.858124 mm
  • Front_Gear_suspension.stl 46.740792 Γ— 55.143944000000005 Γ— 76.368462 mm
  • Hardpoints.stl 129.524727 Γ— 141.689187 Γ— 112.295898 mm
  • Ruder_1.stl 140.015007 Γ— 140.014954 Γ— 98.238037 mm
  • Ruder_2.stl 117.11376999999999 Γ— 117.113869 Γ— 153.758942 mm
  • Servo Covers.stl 122.713272 Γ— 123.81739000000002 Γ— 43.349838 mm
  • Sidewinder_x4.stl 181.736961 Γ— 197.71793300000002 Γ— 13.140883 mm
  • Stabilizer_1.stl 131.38615399999998 Γ— 131.55166300000002 Γ— 91.112221 mm
  • Stabilizer_2.stl 93.476868 Γ— 93.53429399999999 Γ— 115.624893 mm
  • Wing_1_L.stl 181.462986 Γ— 182.949638 Γ— 56.302643 mm
  • Wing_1_R.stl 182.94964599999997 Γ— 181.462982 Γ— 56.302643 mm
  • Wing_2_L.stl 187.863586 Γ— 192.291069 Γ— 151.835022 mm
  • Wing_2_R.stl 192.29107599999998 Γ— 187.863586 Γ— 151.835022 mm
  • Wing_3_L.stl 158.82960500000002 Γ— 161.422821 Γ— 88.978012 mm
  • Wing_3_R.stl 161.422821 Γ— 158.829635 Γ— 88.978012 mm
  • f9f-8t-cougar-rc-70mm-edf-v2.zip
    • Battery tray.stl
    • Canopy transparent.stl
    • Canopy vac.stl
    • Canopy.stl
    • Cockpit.stl
    • Drop tank.stl
    • EDF hatch.stl
    • Elevator.stl
    • Front_Gear_suspension.stl
    • fueling nozzle.stl
    • fuselage_1.stl
    • fuselage_2.stl
    • fuselage_3.stl
    • fuselage_4.stl
    • fuselage_5_new.stl
    • fuselage_6.stl
    • fuselage_7.stl
    • fuselage_8.stl
    • Hardpoints.stl
    • Ruder_1.stl
    • Ruder_2.stl
    • Servo Covers.stl
    • Sidewinder_x4.stl
    • Stabilizer_1.stl
    • Stabilizer_2.stl
    • Wing_1_L.stl
    • Wing_1_R.stl
    • Wing_2_L.stl
    • Wing_2_R.stl
    • Wing_3_L.stl
    • Wing_3_R.stl
    • Aileron_1.stl
    • Aileron_2.stl
  • fueling nozzle.stl 46.474425999999994 Γ— 120.889274 Γ— 8.007301 mm
  • fuselage_1.stl 81.306404 Γ— 81.306428 Γ— 88.321289 mm
  • fuselage_2.stl 109.262542 Γ— 109.262535 Γ— 115.653847 mm
  • fuselage_3.stl 128.987068 Γ— 128.987068 Γ— 110.895752 mm
  • fuselage_4.stl 193.96801799999997 Γ— 193.968033 Γ— 151.46228 mm
  • fuselage_5_new.stl
  • fuselage_6.stl 195.34689400000002 Γ— 195.34695399999998 Γ— 135.338135 mm
  • fuselage_7.stl 180.060043 Γ— 180.059983 Γ— 194.424805 mm
  • fuselage_8.stl 102.63439200000002 Γ— 102.63445999999999 Γ— 163.682678 mm

Learn more about the formats
Last update
Publication date
Design number 1509860
Design author Altsi
Altsi

Altsi

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

A highly detailed and realistic model of the F9F-8B Cougar fighter jet.

The model can be constructed with or without landing gear, with the prototype using the fixed landing gear from my old Habu jet.

IMPORTANT: The CG marked under the Wing is now corrected
The CG in the old files is 10mm too much forward
Thanks steevie

You can watch a video of it in action here:
https://www.youtube.com/watch?v=SVlL0TLynO0&t=1s

The V2 version of the model has additional internal reinforcement and a 5% increase in size, enabling a better fit for a 70mm EDF, as well as redesigned elevators and ailerons. The center of gravity has also been adjusted slightly forward.

The 3D files are watertight and compatible with all slicers for 3D printing.
While assembly instructions are not available at this time, assembly is straightforward and self-explanatory.
I will provide them at a later stage.

Some Files for printing tests are available here:
https://cults3d.com/en/3d-model/game/f9f-8t-cougar-rc-70mm-edf-v2-testfiles

If you have any questions or need assistance, please feel free to contact me.

Requirements:

A printer with a minimum size of 200x200x200mm
LW-PLA filament weighing 500g-750g

Specifications:

Wingspan: 844mm
Length: 1162mm with fueling nozzle
Print weight: 500g-750g LW-PLA
The center of gravity is indicated on the plane's underside

Parts List:

2 HS-45HB servos or equivalent
2 HS55 servos or equivalent
4S LiPo battery, 3300mAh - 4000mAh
FMS 70mm EDF with 2845 KV2750 4S Motor
1000mm Carbon rod, 1mm diameter
500mm Carbon rod or tube, 5mm diameter

Optional: Fixed landing gear (e.g., Habu SS 70mm EDF or any other suitable Habu landing gear) and an additional HS55 or equivalent servo.

Update
- No Parts needed to be mirrored
- Parts are aligned for printing
- Parts are grouped for printing

Update
- Suspension for front landing gear added for users without Habu landing gear set (please print with strong material not LW-PLA)

Update
- Canopy transparent.stl has a higher resolution now

3D printing settings

Use lightweight PLA

0.4mm Nozzle
0.4mm Extrusion Width
0.25mm Layer height
Infill 2-4% (3% for most parts)
Single Outline
2 Top Layers
1 Bottom Layer
No Supports

For the finest result, sand the model and apply a coat of epoxy or polyurethane primer before painting.

The two transparent cockpit parts are best printed using a resin printer or with a vacuum former.

Edit: "Canopy vac.stl" added.
