WiFree Copter ... the RaspPi Zero lerns to fly by Android!

?
Creation's quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
  • 3.2k views
  • 15 likes
  • 148 downloads

3D model description

WiFree Copter
www.open-DIY-projects.com / https://youtu.be/A6Zq8fR1DmM

Description in few words: the WiFree Copter is a 100% 3D-printing Copter, with a Raspbeery Zero and a small flightcontroller inside, controlled by WiFe incl. Live broadcast by Android Smartphone. based on DIY!

Here are the WiFree Project: http://open-diy-projects.com/wifree-copter/
Here the Android APP: http://open-diy-projects.com/topic/die-android-app/
Here the IMAGE for Rasp:http://open-diy-projects.com/topic/raspberry-pi-image-installation-und-verkabelung


3D printing settings

3D-Printing Setup:
HT PLA by Multec
https://www.multec.de/Multec-PLA-HT-Hitzebestaendig

1x Frame top
1x Frame mid
1x Frame bottom
8x Arms
4x landing nobs
1x Battery closer

Additional parts:
4x protectors
4x motor spacer
1x Camspacer

Technical information:
WiFree Copter
– Frame 100% 3D printed HighTemp PLA
– Motors Eachine BG1306 3100KV
– ESC BLHeli20A OneShot 125 OPTO 2-4s
– propeller 5" for example 3x5×4
– FLightcontroller CC3D (or Naze32....)
– Raspberry Zero or Raspberry A+ uor B+ (the Frame is desigend for all!)
– Raspberry Cam (all versions)
– min Wlan dongle
– 5V DC/DC converter (for Flightcontroller and Rasp.)
– Battery 2S/ 850mAh

– Weight without Battery 238g, (Weight with Battery 290g (SLS 850mAh 2S) )
Flighttime around 8min!

3D printer file information

  • 3D design format: STL and ZIP Folder details Close
    • Adapter_f├╝r_kleine_Cam.STL
    • Akku_Deckel.STL
    • Ausleger.STL
    • Frame_mitte.STL
    • Frame_oben.STL
    • Frame_unten.STL
    • Landefu├ƒ.STL
    • Motor_Distanzring_2mm.STL
    • Propellerschutz_5_Zoll.STL
    • WiFree_Copter.zip
  • Publication date: 2016/11/06 at 20:49

License

CC BY NC SA

Tags

Creator

our doing is open Source projects and here is our doing: www.open-diy-projects.com
