Treasure chest Version 2 - Working Lock

Advertising
Share
Add to
Make
?
Creation quality: 4.5/5 (10 votes)
Evaluation of members on the printability, utility, level of detail, etc.
🏆 Best ?
License
Usages
3D design format
13 files (RAR and STL) Close
  • Chest_Bottom_Version_2.stl 122.96799200000001 × 164.103996 × 83.725998 mm
  • Chest_Foot_Version_2.stl 30.220863 × 30.345679999999994 × 9.552841 mm
  • Chest_Package_Version_2.rar
  • Chest_Top_Version_2.stl 120.611991 × 163.764008 × 44.004005 mm
  • Hinge_Pin.stl 8.123772 × 8.123768 × 29.252609 mm
  • Hinge_Pin_End.stl 8.135000999999999 × 8.135001 × 4.869377 mm
  • Key_A.stl 18.303986000000002 × 8.078003 × 42.675987 mm
  • Lock_Back.stl 42.994725 × 42.998743000000005 × 7.221039 mm
  • Lock_Hook.stl 6.3376470000000005 × 7.356167000000001 × 4.6478150000000005 mm
  • Lock_Inner_Ring.stl 26.595704 × 25.116405999999998 × 8.875881999999999 mm
  • Lock_Outer_Ring.stl 46.565109 × 38.723532999999996 × 5.047657 mm
  • Ring.stl 32.403687000000005 × 31.446424 × 5.537764999999999 mm
  • Ring_Holder.stl 19.817189 × 9.201897 × 7.4416199999999995 mm

Learn more about the formats
Publication date
?
Published to Thingiverse on:
Design number 312226
Design author Agroeningen
Agroeningen

Agroeningen

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

A vew changes from the Wooden treasure chest, including a new skin and new feet for a more regal looking treasure chest. Other components have remained the same. the texture might be a bit bubbly here and there but wont be visible when painted up.
https://www.thingiverse.com/thing:4634679

Included in the package are build instructions if needed.

If there are problems or parts need to be adjusted slightly please post a comment and ill try to resolve. Same with any ideas for improvement. Feedback is always welcome!

The model is printable without supports except for "Lock Inner Ring". Appart from that it is advisible to print the chest top and bottom with rafts to prevent lifting of the sharp corners.

Files that need multiples:

Chest Foot x4
Hinge Pin x2
Hinge Pin End x2
Ring x2
Ring Holder x2

Parts that need to be glued:

Chest Foot x4 (depending on how tight it fits)
Hinge Pin End x2 (depending on how tight it fits)
Ring Holder x2
Lock Hook
Lock Back

If the Hinge pin doesnt fit then try sanding it down till its a bit smoother, it needs to be a tight fit for the lid to be able to remain up, but it also shouldnt be completly forced in. Also make sure u have the correct rotation.
