United States 155mm M712 Copperhead Artillery Shell

Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
21 files (STL) Close
  • M712_Copperhead_Base.stl 153.540802 × 153.54080199999999 × 63.329894999999965 mm
  • M712_Copperhead_Driving_Bands_Left.stl 134.959797 × 134.95979699999998 × 30.960296000000028 mm
  • M712_Copperhead_Driving_Bands_Right.stl 132.698059 × 132.698062 × 30.960296000000028 mm
  • M712_Copperhead_Fins_Holder_Support.stl 151.589234 × 151.589234 × 104.09013399999999 mm
  • M712_Copperhead_Head.stl 151.586746 × 151.58675399999998 × 250.62542799999994 mm
  • M712_Copperhead_Lower_Fin.stl 129.29377 × 129.29377000000002 × 106.764587 mm
  • M712_Copperhead_Lower_Fins_Cover.stl 153.683624 × 153.683632 × 239.95980899999998 mm
  • M712_Copperhead_Lower_Fins_Holder.stl 84.511402 × 30.014483999999996 × 68.76852500000001 mm
  • M712_Copperhead_Lower_Obturator_Left.stl 132.943943 × 132.943943 × 19.319489000000004 mm
  • M712_Copperhead_Lower_Obturator_Right.stl 130.27954499999998 × 130.27954400000002 × 19.319489000000004 mm
  • M712_Copperhead_Sensor_Cover.stl 124.760041 × 124.76004 × 106.16558799999996 mm
  • M712_Copperhead_Sensor_Dome.stl 79.57370800000001 × 79.573708 × 40.66204799999991 mm
  • M712_Copperhead_Upper_Fin.stl 153.676124 × 153.676414 × 121.486901 mm
  • M712_Copperhead_Upper_Fins_Break.stl 9.772052999999996 × 9.772057 × 67.27239999999999 mm
  • M712_Copperhead_Upper_Fins_Cover.stl 151.589234 × 151.589234 × 253.890652 mm
  • M712_Copperhead_Upper_Fins_Holder.stl 91.939308 × 43.262926 × 68.808949 mm
  • M712_Copperhead_Upper_Obturator_Left.stl 134.65385 × 134.653854 × 21.37597599999998 mm
  • M712_Copperhead_Upper_Obturator_Right.stl 132.180893 × 132.18089700000002 × 21.37597599999998 mm
  • M712_Copperhead_Warhead_Cover_001.stl 151.588806 × 151.58675399999998 × 180.777131 mm
  • M712_Copperhead_Warhead_Cover_002.stl 151.586746 × 151.586761 × 168.019073 mm
  • M712_Copperhead_Warhead_Cover_Bolt.stl 4.211211999999989 × 11.318817 × 11.318877999999984 mm

Learn more about the formats
Publication date
Design number 3918093
Design author 3DPlus
3DPlus

3DPlus

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

Looking for similar artillery shells? Check this out.
3DPlus
3DPlus
United States 155mm M982 Excalibur Guided Artillery Shell

🔎General Information

This is a detailed 3D model for the United States 155mm M712 Copperhead Artillery Shell. This artillery shell is designed for use with difference artillery systems such as the the M114, M109, M198, M777 and CAESAR howitzers.

The M712 Copperhead is a 155 mm laser-guided artillery projectile developed to engage armored targets with high precision. It is fired from standard NATO 155 mm howitzers and homes in on laser energy reflected from a target designated by a forward observer. Unlike conventional high-explosive shells, Copperhead uses guidance and control surfaces to correct its flight path during descent. This allows it to achieve significantly greater accuracy against high-value targets such as tanks.

⚠️Disclaimer: This model is intended for visual and decorative purposes only. It is non-functional and cannot be modified to operate as a real device. I am not liable for any misuse of the printed items. Rendered images with paint and markings are for illustrative purposes only. The files are provided under the Cults Private Use License.

🧩Contents (21 Parts):

This M712 Copperhead artillery shell pack includes a total of 21 parts, detailed as follows: the shell body consists of 9 parts; the obturator and driving bands are made up of 6 parts; the fins, fin holder, and fin break consist of 5 parts (You will need to print each part four times); one body bolt is included (14 copies of the body bolt are needed).

All files are compatible with 250mm build height printers

The model is real size scale

✅Happy printing.

Have a special request or need a commercial license? Please contact me at: simulation.plus.yt@gmail.com

3D printing settings

🛠️These models are optimized for smooth printing using the following settings:
• Layer Height (Resolution): 0.1 mm or 0.2 mm (A larger resolution, is suitable for printing bigger parts.)
• Nozzle Size: 0.4 mm
• Nozzle Temperature: 205 °C

You should experience no printing issues with these parameters.
