Tamiya TT-02 RWD Conversion

Tamiya TT-02 RWD Conversion . You will need 6pcs of 5mm pins 2x 21mm length and 4x 14mm length . 21mm for upper arms and 14mm for lower arms . There are 2 different lengths of upper arms , long can be used as is with a ball end and short can be used with turnbuckles for camber adjustment.There are also 2 types of lower arms included . Lower arm V2 is the standard length and can be used with just a ball end as in the pictures (you will need a M3x50mm screw that goes throu the arm for strength and mounting the ball end .I have used Yokomo ball studs and ball cups , (IB-414KB2 and Y2-008FU) . Lower arm V2 Adjustable must be used with spacers to adjust the total width of the front but you must use the short upper arms with turnbuckles.
Lower and upper arms can be used in both sides just flip them , but if you like uniform looks you can just mirror the parts in the slicer . Steering wipers have many holes for ackerman adjustment . I like it best on the center hole as in the pictures . You will also need 2x 28mm turnbuckles for steering . I have also used yokomo ball studs and ball cups for steering as well ( ZC-206SHS and Y4-207) . You will also need 2x M3x16mm screws for the knuckle stoppers at full angle. I also used yokomo front axles (Y2-010F or Y2-010FAA) . There are 8mm front hexes included if you dont have wheels with enough offset so you wont rub on the arms .This conversion kit is not for beginners it will need some tuning and work on 3d printed parts . Please be aware of that. I can help you build it in some extent , you can contact me on my socials listed on my profile.

Small video of the car drifting with the conversion(not much power due to stock brushed motor) : https://youtu.be/6fsYF5pemV8

Printed in 0.2mm Height with supports from the build plate .
