Performance Wheels "Spitfire" 6 Slot Rim

Next-Gen Rim Design | Precision. Flexibility. Detail.

Experience the realism and flexibility of our Next-Gen Rim Design—crafted for scale model cars from 1:64 through 1:18.
Each file is designed with exceptional accuracy and strength, ensuring stunning results even at small scales.

What's Included

You’ll receive a comprehensive set of STL files, giving you full control and customization options.

These typically consist of:
1. Rim with Hub
2. Rim with Hub (No Badge)
3. Rim with Hub (No Badge, Larger Centre)
4. Rim without Hub
5. Rim without Hub (No Badge)
6. Rim without Hub (No Badge, Larger Centre)
7. Rim Face (when applicable)
8. Rim Face with Badge (when applicable)
9. Outer Rim (when applicable)
10. Sleeve
11. Hub (Standard)
12. Badge
Actual files can be viewed by clicking beside “3D Design Format”

Key Features

• Accurate Design: Modelled directly from the original rim for true-to-scale detail.
• Solid Construction: Thicker faces and outer rims provide enhanced durability—ideal for smaller prints.
• Dimensions: 100mm x 50mm with a 10mm centre (@100% print).
• Scalable: Easily adjust for 1:18, 1:25, 1:32, 1:43, and 1:64 scales.

Scaling Guide

To calculate scale:
- 1:18 Scale: Real rim ÷ 18
- 1:25 Scale: Real rim ÷ 25
- 1:32 Scale: Real rim ÷ 32
- 1:43 Scale: Real rim ÷ 43
- 1:64 Scale: Real rim ÷ 64

Example:
A real 19" rim in 1:32 scale → 19 ÷ 32 = 0.59 inches / 25.4mm (≈25.4% of file size).

If using our tyre files (sized for a 100mm rim), scale them by the same percentage. For best fit, make tyres slightly larger to allow for print, cure, and paint tolerances.

Compatibility

• Standard Hub: Perfect for 1:64–1:43 models using push axles.
• Through Axles (Hot Wheels style): Use the "With Hub, No Badge, Larger Centre" file — drill if necessary for smooth rotation.
• Larger Scale Models: Use "Rim Without Hub"; compatible hubs are available separately from our store. link
• Rubber Tyres: For secure mounting, use our Tyre Retainer Ring Set available from Cults3D store. link

Need a hand?

Check out our YouTube Channel for how-to videos and tutorials designed to help you succeed. Like & Subscribe to never miss a new guide!

License & Usage

• Files are for personal use only — not to be shared, sold, or uploaded elsewhere.
• To sell physical prints, a Commercial License is required. link

At Scale Model Wheels and Design, we take pride in crafting authentic, print-ready files that bring real-world wheels to scale.

Follow us for new releases and see how our designs can transform your next build.

#ScaleModelWheels

Recommended Print Settings

Printer:
Resin printer for smaller scales (1:64–1:25)
FDM printer for larger scales (1:25–1:18)

Material:
Resin / PETG / PLA

Print Orientation:
Rotate 35-45°, with the rim face angled upward for best surface finish.

Supports:
Where possible, add supports to the outer rim and centre hub only.
Avoid excessive supports on the rim face, particularly with spoked designs, to preserve fine detail.

Quality Control

Each file has been thoroughly checked for geometry faults and print readiness prior to listing to ensure consistent quality.
If you experience any issues with your print, please contact us at scalemodelwheels@outlook.com
— we’ll work with you to resolve it promptly.
