SP511E / SP611E / SP617E CONTROLLER BOX AND REMOTE INSTALL

This is one of my first 3D designs with my Ender 3 V2.

As I am dedicated to share content in @ledsdireccionables I decided to prepare the boxes and knobs of this type of ARGB controllers. The ones that don't come with fixtures as standard, of course.

Both the case mount and the remote control mount have gone through the beta process to their final design.

The bracket for the controller is designed to insert the cables one by one, save the perforation of the power cable and built-in microphone and anchor just enough to be fixed on any flat surface.

Both are drilled and ready to be anchored with screws, where the screw head is barely embossed. NOTE: It is necessary to choose the screw well, in the photos you can see the type of head. A larger head would cause a bad fit of the elements, and a smaller one, it would slip through the hole.

I repeat, just in case: They are designed exclusively for the SP511E, SP611E and SP617E controllers.

12/03/22 UPDATE: Added ThinV2 version with 30% less material and better fit without forcing.

PLA and standard temperatures and speeds.

Yes it is true that in the case of the design for the knob, support may need to be added for the top area. I added a little more material in that area in height so that if the filament drops, the top layers will still look perfect and do their job.
