Snapfit Enclosure for ESP8266 Sinilink XY-WFMS 5V-36V Mosfet Switch Module

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 1.3k views
  • 23 downloads

3D model description

A small box for the cheap Sinilink XY-WFMS module. It is with a snapfit so no extra screws are required.

Instead of using the chinese app it comes with I flashed Tasmota on it and created this Template. In the Tasmota template u can also set the mosfet pin to 'PWM1 (37)' instead of using it as a 'Relay1 (21)'. I use this to dim about 4 meters of 12V LED strip which is working without a problem.

I bought my Sinilink XY-WFMS Module on AliExpress

I also included the Autodesk Fusion 360 project.

  • 3D file format: F3D and STL
  • Publication date: 2020/04/23 at 11:14
