Rotating Display Platform

Rotating Display Platform

This rotating display platform is produced using 3D printing technology and features a 110 mm diameter rotating table. It is an ideal solution for elegantly showcasing the products you want to display.

Technical Specifications:
• Motor: The platform is driven by a 28BYJ-48 stepper motor, known for its low power consumption and precise movement capability.
• Rechargeability: Powered by a 18650 lithium-ion battery, making it portable.
• Charging Module: Equipped with a TP4056 charging module, ensuring safe charging of the platform.
• Connection Type: Features a Type-C port, providing a modern and widely used charging connection.
• Power Management: The voltage from the 18650 battery is boosted by a voltage step-up module to power the stepper motor and microcontroller properly.
• Control: A built-in potentiometer allows manual adjustment of the rotation speed.

Applications:
• Product Display (e.g., jewelry, watches, model cars).
• Photography and Video Production, serving as a rotating platform.
• Showcasing 3D-printed models dynamically.

Required Components List:

• Microcontroller

• BYJ-48 Stepper Motor and Driver

• Voltage Booster Module

• Charging Module (TP4056 or equivalent)

• 18650 Battery

• On/Off Switch

• 4x M4 15mm Screws

• 2x 608ZZ Bearings

This design stands out for its portable and practical usability. Thanks to its rechargeable battery, it can be used anywhere without the need for a power outlet. Additionally, the stepper motor ensures smooth and precise rotations, allowing products to be professionally showcased.

Recommended Print Settings:
I printed the model with a 0.2 mm layer height and a 15% infill density. I recommend enabling support generation in automatic mode, so that supports are only added where necessary. This way, only 0.40 grams of filament is used for support material.
