Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid

Rohrbogen_45,2_R51___M6x45___2026-Feb-20_09-09-56PM-000_CustomizedView237560873.png Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
BILD_Allgemein_01.jpg Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
BILD_Allgemein_02.jpg Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
RoB 45,2 R51 Oben.stl Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
RoB 45,2 R51 Unten.stl Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
Rohrbogen_45,2_R51___M6x45___2026-Feb-20_09-09-56PM-000_CustomizedView237560873.png Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
BILD_Allgemein_01.jpg Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
BILD_Allgemein_02.jpg Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
RoB 45,2 R51 Oben.stl Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
RoB 45,2 R51 Unten.stl Pipe elbow sawing aid 45.2mm R51, elbow welding elbow cutting aid
Make an offer
Share
Add to
Make
?
Creation quality: 0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
2 files (STL) Close
  • RoB 45,2 R51 Oben.stl 80.849998 × 78.849998 × 37.850001 mm
  • RoB 45,2 R51 Unten.stl 80.849998 × 78.849998 × 27.35 mm

Learn more about the formats
Publication date
Design number 4061269
Design author HM-GARAGE
HM-GARAGE

HM-GARAGE

Issue with this design? Report a problem.

3D printer file info

3D model description

Die mittels 3D Druck hergestellte Vorrichtung ermöglicht das präzise Absägen eines Rohrbogens im korrekten Radius z.B. mit einer Bandsäge. Der Anschlag kann alle 5 Grad mithilfe eines 2mm-Schweißdrahts abgesteckt werden. Der Rohrbogen kann durch anziehen der verbauten Schrauben fixiert werden, daher eignet sich die Vorrichtung auch als Anzeichenhilfe. Beim Spannen im Schraubstock können die Schrauben auch weggelassen werden, da Führungen vorhanden sind.
Es handelt sich um Schweißbogen nach DIN 2605 bzw. EN10253-4 oder DIN 11852.

Besonders nützlich für den Bau von Abgasanlagen, Rohrleitungsbau, Krümmer- oder Ladeluftverrohrungen. Geeignet für Stahlguss, Edelstahl- oder Aluminium Rohrbögen.

Falls Sie die Vorrichtung in einer anderen Größe benötigen, lassen Sie es mich einfach wissen.

Benötiges Material:
- 2x DIN 912 Zylinderschrauben M6x45
- 2x DIN 934 Sechskantmutter M6
- 2mm Schweißdraht Länge: 54mm

3D printing settings

Material: PLA / PETG
Nozzle 0.4
5 Wandlinien
Schichthöhe 0,2
18% Infill
Stützstruktur EIN
