Mitutoyo Caliper Work desk holder and bracket

Micrometer-work-desk-holder-bracket.jpg Mitutoyo Caliper Work desk holder and bracket
Caliper holder.obj Mitutoyo Caliper Work desk holder and bracket
Dowel.obj Mitutoyo Caliper Work desk holder and bracket
Bulldog clip holder.obj Mitutoyo Caliper Work desk holder and bracket
Work desk bracket v1.obj Mitutoyo Caliper Work desk holder and bracket
Micrometer-work-desk-holder-bracket.jpg Mitutoyo Caliper Work desk holder and bracket
Caliper holder.obj Mitutoyo Caliper Work desk holder and bracket
Dowel.obj Mitutoyo Caliper Work desk holder and bracket
Bulldog clip holder.obj Mitutoyo Caliper Work desk holder and bracket
Work desk bracket v1.obj Mitutoyo Caliper Work desk holder and bracket
Advertising
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
4 files (OBJ) Close
  • Bulldog clip holder.obj 17.0 × 50.0 × 50.0 mm
  • Caliper holder.obj 20.0 × 49.999377 × 100.249683 mm
  • Dowel.obj 8.992929 × 7.985858 × 13.546999000000001 mm
  • Work desk bracket v1.obj 30.0 × 50.0 × 18.896999 mm

Learn more about the formats
Publication date
Design number 1337457
Design author Neogame
Neogame

Neogame

Issue with this design? Report a problem.

3D printer file info

3D model description

Optimize precision in your workspace with our Mitutoyo Caliper Work Desk Holder and Bracket. Keep your calipers easily accessible, promoting efficiency and accuracy. Elevate your measurement processes by integrating this essential accessory into your setup. Upgrade your work desk today for seamless results!

If you have a desk at work with the same Aluminium feature at the top as shown then you can use this bracket to hold anything, here is my design for a mitutoyo caliper holder.

The main bracket uses 1 x M4 nut with a M4 Grub screw to secure in place after finding the right spot (glue the M4 nut in) then 2 x M6 nuts and Cap head screws to attach any holder, there is a location dowel that slides into the holder to help align to the bracket.

Pitch between the M6 holes is 25mm.

3D printing settings

No special settings required

Categories

All categories › Tool › 3D Printing & Accessories / DIY

Tags
