GEN2 1x1 Decor Gridfinity Magnet Single Drawer - STANDARD

| Visit JERRARI.com for Instructions and a complete look at the GEN2 collection

The GEN2 Decor Series is the next evolution in the most versatile 3D printed drawer system, The GEN2 Modular Storage System. You can now easily swap faceplate and handles to fit the mood of the room you want. Being able to easily customize colors, patterns, or adding custom text.

This GEN2 Decor Drawers - STANDARD is a collection of the standard length drawer bodies. The bodies can be printed in any material, slap any sleek GEN2 Decor faceplate and handle/knob to the front, and BAM! You got yourself something that will look at home in any room.

What you need?
These drawers are completely compatible and interchangeable with any GEN2 drawer systems in STANDARD length.

To find all the available faceplates visit GEN2 Decor Series at JERRARI.com

HARDWARE
Includes affiliated links to help support my projects
• Filament - Black PETG (My go to for the drawer bodies)
• Screwdriver
• Countersunk woodscrews: (Metric: 4x25mm to 4x16mm) or (SAE: #6 or #8 up to 1" long)
• Drill bit that is smaller diameter than the wood screws
• Pen, Marker, or Scratch Awl (for installing under tables)
• Magnets (Optional): 10x5x2mm or 10x2mm
• M3 nuts and screws: M3x6 - M3x10- I prefer this kit
For basic instruction on assembly please check out the above video

INSTRUCTIONS
• Push M3 nuts into slots on handles/knobs

• After sliding the faceplate into position on the GEN2 Decor Drawer use a M3 screw starting it from inside the front of the drawer, passing it through the faceplate and thread it into the M3 nut on the handle, securing it in place.

• As noted above you'll also need a GEN2 system of your choice, don't worry, they are fully modular and can be changed around at any time.

Gridfinity designed by Zack Freedman
Magnetic Gridfinity developed using Actually Parametric Gridfinity – Base Grid + Bins
