  • Center.stl 16.5 × 16.5 × 10.274999999999999 mm
  • Connector_female.stl 18.0 × 17.996928 × 17.5 mm
  • Coupler4.stl 18.0 × 18.0 × 29.25 mm
  • Coupler5.stl 18.0 × 18.0 × 29.25 mm
  • Files_xcoupler.zip
    • Connector Female Long.stl
    • Connector Male Long.stl
    • Coupler Connector Female Long.stl
    • X-Center.stl
    • X-Coupler Female.stl
    • X-Coupler4mm.stl
    • X-Coupler5mm.stl
  • X_Couple_Female.stl 18.0 × 18.0 × 22.25 mm
  • X_Coupler_Male.stl 18.0 × 17.99924 × 17.0 mm

Learn more about the formats
Last update
Publication date
Design number 4083072
Design author hermor
hermor

hermor

Certified account
Issue with this design? Report a problem.

3D printer file info

3D model description

Cardan joint, suitable for 4 or 5mm axles.

The axle size can also be adjusted by drilling the hole to the desired size.

The Cardan coupling can be combined with a connector to create a non-permanent shaft connection.

Combine the parts as desired.

Fileset:
X-Coupler 4mm shaft
X-Coupler 5mm shaft
X-Center
X-Coupler-Connector Female
Connector Male Long
Connector Female Long
X-Coupler-Connector Female Long

The M4 thread for the fixing bolts needs to be re-tapped with an M4 tap.

Drill the holes for the hinge with a drill so that the pins fit loosely and can hinge smoothly.

Printing in PETG or another suitable material

3D printing settings

Printbed: all
Filament: PETG
Supports: No
Settings: 04,4mm nozzle, 4 walls, 50% infill.
