Attachment for wire rope
:still():format(webp)/https://files.cults3d.com/uploaders/12916954/illustration-file/e188c25a-88c5-4244-bad1-f770ea24c68a/Capture%20d%E2%80%99e%CC%81cran%202017-10-31%20a%CC%80%2015.29.53.png)
?
Creation quality:
5.0/5
(1 votevotes)
Evaluation of members on the printability, utility, level of detail, etc.
Your rating:
0/5
- 4.5k views
- 13 likes
- 251 downloads
- <span class="text--light">0</span> comments
- <span class="text--light">0</span> makes
Designer
3D model description
For fixing some platforms an a hanging wire rope i designed this clamps.
The target was, to create a clamp witch can be 3d-printed and mounted with simple tools.
The files work perfect with an wire rope Ø2mm
If you need a different diameter let me know.
https://youtu.be/e1bMrzUsjzk
http://ewap.ch/?p=135
wire rope on amazon: http://amzn.to/2bpl9SC
3D printing settings
Printer:
Prusa i3
Rafts:
Doesn't Matter
Supports:
No
Resolution:
0.2-0.1mm
Infill:
50%-100%
Notes:
As better the resolution is, the better you can press the two parts together.
3D printer file information
- Design number: 16294
-
3D design format: STL Folder details Close
- Kabelbride_1.stl
- Kabelbride_1b.stl
- Publication date: 2017-10-31 at 14:42
License
CC BY-NC-SA - Attribution - Non commercial - Share alike
