ADXL345 Accelerometer Mount for Ender 3 S1 X Axis / Sprite Extruder

277373016_3152153591770502_8928498279804731268_n.jpg ADXL345 Accelerometer Mount for Ender 3 S1 X Axis / Sprite Extruder
ADXL345 Accelerometer Mount for Ender 3 S1 X Axis.stl ADXL345 Accelerometer Mount for Ender 3 S1 X Axis / Sprite Extruder
8mm Spacer.stl ADXL345 Accelerometer Mount for Ender 3 S1 X Axis / Sprite Extruder
277373016_3152153591770502_8928498279804731268_n.jpg ADXL345 Accelerometer Mount for Ender 3 S1 X Axis / Sprite Extruder
ADXL345 Accelerometer Mount for Ender 3 S1 X Axis.stl ADXL345 Accelerometer Mount for Ender 3 S1 X Axis / Sprite Extruder
8mm Spacer.stl ADXL345 Accelerometer Mount for Ender 3 S1 X Axis / Sprite Extruder
Advertising
Share
Add to
Make
?
Creation quality: 5/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
License
3D design format
2 files (STL) Close
  • 8mm Spacer.stl 5.2 ร— 5.198917999999999 ร— 8.0 mm
  • ADXL345 Accelerometer Mount for Ender 3 S1 X Axis.stl 29.0 ร— 14.75 ร— 38.5 mm

Learn more about the formats
Publication date
Design number 681885
Design author crater
crater

crater

Issue with this design? Report a problem.

3D printer file info

3D model description

This bracket allows for an ADXL345 accelerometer to be mounted to the extruder of the Creality Ender 3 S1 / Sprite Extruder for calibrating X axis resonance compensation in Klipper.

It uses the existing upper two mounting screws for connection to the extruder.

Two M3 machine screws self-tap into the bracket for mounting of the accelerometer. Ideal screw length is 4mm.

Note that in the photo I've used 12mm long screws with 8mm long spacers since I didn't have screws of the correct length. I've included the spacer file which can be scaled for other screw lengths.
