3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit

007.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
003.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
CE3PRO_3.5 22.5 degree 3.5 clr bend - Ultimaker Cura - x File Edit View Settings Extensions Preferences Help Ultimaker Cura taut oT) Generic PLA = 2 v “ar oD Creality Ender-3 Pro O Sree 32 comgrow pla +} a a lity-0.2mm & 20% Ny 2 5 & a DS snap Rotation rid —" 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
Elle Edit View ~— Settings Extensions Preferences Help Ultimaker Cura Pad MONITOR Layer view Color scheme Line Type 279 Beene © 10 hours 59 minutes @ Z CESPRO_35 straight Somm height © 68g: 22.70m 90.9x5. fi amy")! ewanad P Type here to search Oo 9:52 PM. 7/05/2022 12c A GE mh) @ ENG 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
ei ed meres 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
002.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
004.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
005.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
n ele Hola p : eenneniernnrey winseiy tet cmmad ~ Hy PT eee lee nla I Leeman . » oT cm ie } sn a \S + \ A 3 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 11.25 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 22.5 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 45 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 90 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 20mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 25mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 30mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 40mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 50mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 100mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
007.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
003.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
CE3PRO_3.5 22.5 degree 3.5 clr bend - Ultimaker Cura - x File Edit View Settings Extensions Preferences Help Ultimaker Cura taut oT) Generic PLA = 2 v “ar oD Creality Ender-3 Pro O Sree 32 comgrow pla +} a a lity-0.2mm & 20% Ny 2 5 & a DS snap Rotation rid —" 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
Elle Edit View ~— Settings Extensions Preferences Help Ultimaker Cura Pad MONITOR Layer view Color scheme Line Type 279 Beene © 10 hours 59 minutes @ Z CESPRO_35 straight Somm height © 68g: 22.70m 90.9x5. fi amy")! ewanad P Type here to search Oo 9:52 PM. 7/05/2022 12c A GE mh) @ ENG 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
ei ed meres 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
002.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
004.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
005.jpg 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
n ele Hola p : eenneniernnrey winseiy tet cmmad ~ Hy PT eee lee nla I Leeman . » oT cm ie } sn a \S + \ A 3 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 11.25 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 22.5 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 45 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0'' 3.0'' CLR 90 deg bend.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 20mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 25mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 30mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 40mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 50mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
3.0 straight 100mm height.STL 3.0" OD 3.0" CLR (exhaust) pipe/tube bend mock up kit
Advertising
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
3D design format
10 files (STL) Close
  • 3.0 straight 100mm height.STL
  • 3.0 straight 20mm height.STL
  • 3.0 straight 25mm height.STL
  • 3.0 straight 30mm height.STL
  • 3.0 straight 40mm height.STL
  • 3.0 straight 50mm height.STL
  • 3.0'' 3.0'' CLR 11.25 deg bend.STL
  • 3.0'' 3.0'' CLR 22.5 deg bend.STL
  • 3.0'' 3.0'' CLR 45 deg bend.STL
  • 3.0'' 3.0'' CLR 90 deg bend.STL

Learn more about the formats
Publication date
Design number 718243
Design author lockdesigns
lockdesigns

lockdesigns

Issue with this design? Report a problem.

3D printer file info

3D model description

3.0" 3d printed pipe/tube bends in modular form used to create a template for fabricating dump pipes, intercooler pipes, exhaust pipes and more for the serious car enthusiast /fabricator
these are built heavy duty to with 5mm wall thickness and top and bottom to last in a workshop environment
there are a range of angled cuts available 11.25, 22.5, 45 , 90 as well as straight sections 20mm, 25mm, 30 mm, 40mm,50mm, 75mm, 100mm all included in this buy
this 3.0" Centre line radius suits most common "exhaust" dohnuts that are on the market

this kit is 3.0" OD and 3.0" CLR

note: I am adding different pieces as i draw them up and test them so collection will progressively get bigger as i go on.

3D printing settings

SIZE :1:1
PRINT ORIENTATION : BIG HOLE DOWN(as per photos
MATERIAL : PLA (or whatever you want)
SUPPORT: YES (i use towers with interfaces on roof and touching buildplate only look at photos for a rough idea, different amount of support overhang angle required depending on which pieces)
BUILD PLATE ADHESION : BRIM ONLY
INFILL: 20 % DENISTY
INFILL PATTERN GRID (can experiment with others)
PRINT TIME : 8-10 HOURS PER PIECE (thats just my experience printing at 40mm/s on ender 3 pro, can be played with to better)

Categories

All categories › Tools

Tags
