Om Nom Lamp, cut the rope candy LED light

?
Creation's quality: 0.0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
  • 306 views
  • 1 like
  • 5 downloads

3D model description

My daughter is Om Nom's #1 fan so I made her a night light! Actually its fairly bright so well use it to supplement story time.

MATERIALS: (Please do utilize my affiliate links if you make this device, thanks!)
Translucent PLA Yellow- https://amzn.to/2N32u04
Translucent PLA Yellow- https://amzn.to/37VF30L
LED Module- https://amzn.to/2SYHHOZ
Finger nail Polish (Set)- https://amzn.to/2N6UVVZ

Hand painted with cheap fingernail polish which adheres to PLA nicely. Use 2 coats for the white so the light doesnt come through the eyes and make it look funny. I printed the parts in green & yellow, then painted on the white black & red. The candy has raised edges where the stripes go to guide painting.

The candy is superglued to the om nom, which is designed with clearance so they fit together just so!

Print the candy without supports. Print the Omnom WITH supports & ~10 solid top layers + 10% gyroid infill. (We want to let some light through but it must be diffuse and not overpower the character.)

The lower shell of USB LED light is thrown away but we keep the domed diffuser. Ive provided no instruction because its literally as easy as it looks from my photos. Zip tie the cable to the LED as a strain relief, then glue in teh LED disc (super glue but NOT hot glue as the LEDS do get warm). Then glue on the dome diffuser, then glue the enture like disc assembly into the back of the candy.

  • 3D file format: STL
  • Publication date: 2020/10/14 at 18:42

License

CC BY NC SA
