  • Endstück.stl 119.999998 × 30.0 × 22.200001 mm
  • Feststellknopf.stl 27.999998 × 16.0 × 18.0 mm
  • Luftauslass.stl 121.072124 × 120.0 × 58.0 mm
  • Lüftergitter.stl 120.0 × 120.0 × 3.0 mm
  • Standfuss.stl 120.0 × 95.00000200000001 × 15.0 mm
  • Verbinder.stl 119.99999700000001 × 30.0 × 40.200001 mm

Learn more about the formats
Publication date
Design number 1617765
Design author tomivol
tomivol

tomivol

Issue with this design? Report a problem.

3D printer file info

3D model description

Heating booster promotes heat exchange in panel radiators.

The cold air on the floor is sucked in by the fans and conveyed upwards behind the radiator by means of the 90° arc. It exits above the radiator warmed up again. The thermal energy behind the radiator is thus supported.

This version is operated with 3x 120 mm PC fans. The number can be increased as required. The entire part consists of the 2 end pieces with the movable base to adapt it to the radiator height, minimum height is 120 mm, maximum 165 mm, the base can be scaled in the slicer if required.

The stand is only available once and must be printed out mirrored in the slicer.2x M5x25 hexagon head screw for fastening the stand in the guide groove.

The booster is used in conjunction with 12V thermostat, kit W1209 available at Amazon, housing is printed by yourself, files at Thingiverse. Sensor attached to the heater and the fans switch on when the heater turns on.

Device is extremely quiet because

  1. large fans with significantly lower speed for the same output

  2. fans are not connected to the radiator, so no vibration transmission.

3D printing settings

Material PLA Infill 20% is sufficient
