Google Nest Hub Articulated Arm Mounting Bracket

Screenshot-from-2022-07-14-07-09-39.png Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Arm-Long.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Arm-Short.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Arm-Medium.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Arm-Mount.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Nest-Mount.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Arm-Clip.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Wall-Mount.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Nest-Hub-Articulated-Bracket-Cup-Mount.stl Free STL file Google Nest Hub Articulated Arm Mounting Bracket・3D printing idea to download
Share
Add to
Make
?
Creation quality: 5.0/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.

Designer

ulsmith

ulsmith

3D model description

There is a few out there to be fair, but none that offered what i wanted which was a flat screen TV style mount.

So here is my own articulated nest hub bracket. Comes with various size arms and the ability to add as many or little arms as wanted to get desired reach.

Requires a few screws, M3x14/16 should work, holes should self tap.

Has a nice tight ball joint on the end for final tilting... plug in the ball into the socket with the flats matching, then twist 90 degrees (might need pliers or a vice, can be a little hard), this will lock the ball in place. Ball joint is pretty tight at first.

ring slips over nest hub base once unplugged, snug fit...

Now with stronger and smaller wall mount to allow 100% infill printing on this, its the weakest part of the setup so needs to be the strongest.

Also added locking holes on ball joints for locking screws.

Enjoys peoples!!

3D printing settings

0.4 nozzle... no supports needed

Print the wall mount 100% infill for strength as it takes most of the weight at this point.
