Flower pot with overflow tray

Update 2025-03-19
I had a request for a larger flower pot one with a 25cm diameter. A new larger flower pot has been uploaded. Images will be added soon.
Dimensions are that is 22cm base, 25 cm top and 22cm high

Yes it's another flower pot. .. The flower pot is equipped with a removable tray to empty out any access water. The tray is secured to the flower pot using grip fins.
The flower has a diameter of 14 cm x 14.5 cm high

This really started off as an experiment that went well where a few work colleagues wanted one as well. So I decided to share it. My wife bought a cheap flower pot on line that was too small so I decided to create a parametrised version. where I could set the top & button diameters and the Hight.

Once I figure out how to create a parametrized version on cults will set it up.

The flower pot prints well, I have provided print instruction to keep filament usage under control. I will be uploaded version 2 which will simplify the print and minimised Internal solid Infill

The flower pot is a simple print but slicer settings are required to minimise excessive "Internal Solid Infill". Enabling these setting can save 2hrs of print time and significant amount of filament as well.

25 cm Flower Pot
The 25 cm pot has been uploaded as a single stl file that contains both parts. Just concert to object to print separately.

.4 nozzle, .2 layer Hight, no support, 5 %infill,
Pot's Tray special settings not required.

For flower pot use these special setting :
Under strength settings

• Disable "Ensure Vertical Shell Thickness"
• Set "Minimum Sparse Threshold" to zero
