Base AA.STL Battery Dispenser - for AA and AAA Batteries
Base AAA.STL Battery Dispenser - for AA and AAA Batteries
Housing AA.STL Battery Dispenser - for AA and AAA Batteries
Housing AAA.STL Battery Dispenser - for AA and AAA Batteries
Revolver AA.STL Battery Dispenser - for AA and AAA Batteries
Revolver AAA.STL Battery Dispenser - for AA and AAA Batteries
Trigger AA.STL Battery Dispenser - for AA and AAA Batteries
Trigger AAA.STL Battery Dispenser - for AA and AAA Batteries
Advertising
Share
Add to
Make
?
Creation quality: 5.0/5 (2 votes)
Evaluation of members on the printability, utility, level of detail, etc.
Licence CULTS - Private Use
Publication date 2023-06-16 at 08:28
Design number 1274343
3D design format
STL Folder details Close
  • Base AA.STL
  • Base AAA.STL
  • Housing AA.STL
  • Housing AAA.STL
  • Revolver AA.STL
  • Revolver AAA.STL
  • Trigger AA.STL
  • Trigger AAA.STL

Learn more about the formats
layerfuse_design

layerfuse_design

3D printer file info

3D model description

This is a more advanced design of a battery dispenser.
I designed this, because all other battery containers you can download are very boring.

This dispensers are very compact and can hold up to 8 batteries.

There are 2 Versions - one for AA (Mignon) cells
and one for AAA (Micro) cells.

This design looks very complicated, but its easy to print.

For assembly you need a spring with 7-9,5mm diameter
and 34-40mm length.
You can buy such springs for cheap on Amazon.
If you cant find these spring dimensions, you can buy a standard spring assortment box, they normaly contain these dimensions.
If you have a spring with the right diameter but its to short, you can stretch it by hand to the right length - i tried it and it works fine.

Watch my youtube video and the uploaded picture for assembly instructions.

If you like this design, please follow me.
I have a lot more awesome designs in planning.

3D printing settings

Material: PLA, PETG or ABS
3 Perimeters
20% Infill

Supports: You need supports only for the small overhang
on the Triggers

https://youtu.be/p6wdhpdO_Js
