decoupe_haut.STL zohd altus Vtol conversion
decoupe_bas.STL zohd altus Vtol conversion
nacelle_servo_v5.STL zohd altus Vtol conversion
nacelle_v5.STL zohd altus Vtol conversion
servos_mount_base.STL zohd altus Vtol conversion
nacelle_roulement_v5.STL zohd altus Vtol conversion
preview.jpg zohd altus Vtol conversion
image.jpg zohd altus Vtol conversion
photos.jpg zohd altus Vtol conversion
20250217_103354_HDR.jpg zohd altus Vtol conversion
20250217_103342.jpg zohd altus Vtol conversion
20250217_103328_HDR.jpg zohd altus Vtol conversion
20250217_103334.jpg zohd altus Vtol conversion
20250214_223708.jpg zohd altus Vtol conversion
decoupe_haut.STL zohd altus Vtol conversion
decoupe_bas.STL zohd altus Vtol conversion
nacelle_servo_v5.STL zohd altus Vtol conversion
nacelle_v5.STL zohd altus Vtol conversion
servos_mount_base.STL zohd altus Vtol conversion
nacelle_roulement_v5.STL zohd altus Vtol conversion
Advertising
Download US$ 1.16+
Make an offer
Share
Add to
Make
?
Creation quality: 5/5 (1 vote)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
6 files (STL) Close
  • decoupe_bas.STL
  • decoupe_haut.STL
  • nacelle_roulement_v5.STL
  • nacelle_servo_v5.STL
  • nacelle_v5.STL
  • servos_mount_base.STL

Learn more about the formats
Publication date
Design number 2708960
Design author mopi007
mopi007

mopi007

Issue with this design? Report a problem.

3D printer file info

3D model description

I wanted something light and functional. I already had the servos, so buying the kit was too expensive.

You'll need:

2 screws M2 16mm2 nut M2
8 small plastic screws 2mm diameter and 6mm long
4 screws for plastic 2mm diameter and 10mm long (or more)
2 ball bearings MR74 ZZ (4x7x2.5mm, 0740)

2 servos PTK 7455 MG
I replaced the original ESCs with LITTLEBEE SPRING 30A 2-6sESC

I kept the original motors and used Nazgul 6043 6x4x3

thanks to https://rcmodelytt.sk/zohd-altus-vtol/
for the inspiration.

3D printing settings

I printed everything with 0.4mm petg carbon
for most of it, with 0.8mm walls and 20% filling. It's really very solid! and the servo support weighs just 10gr bare. You need to add the bearing + servo + moving nacelle + screws and bolts.
you need to reproduce the second part of all servo mounts in mirror mode.
