Modular Counter V2 - Commercial License

This is a Commercial Licensed version of a Clicking Modular Counter V2
More about a license above 'Print settings' section

Version for Personal Use Only is here:
https://cults3d.com/en/creations/modular-counter-v2

Models are the same

My Tabletop collection - including free 2 and 3-digit counters
https://cults3d.com/en/design-collections/c47/tabletop

• Make your own counter for hp / score / mana / etc. With as many digits as you want You can even combine it all in one counter to use less space and have better organization (especially usefull in rpg games)
• Choose between 1.2cm (little easier to use) or 0.8cm (use less space) thick wheels
• Carved or Domed numbers on weels - as you like
• Counted number on top of the stand or angled (36*)

On photos you can see some examples:
Multicolor print with 2 digits with original wheels
Dual color as on typical printers with pause and filament change with 6 (!) digits sepparated by middle stand part with short wheels
Single color prints with 3 digits on short wheels

For numbers I used a Gentium Basic Bold Italic font licensed under the SIL Open Font License, Version 1.1

What do you need to make a counter
You can also see ModularCounterV2_Instruction.jpg

• Stand-male (TOP or ANGLE)
• Stand-female (same version as male)
• Center or Center-SHORT - as many as many digits you want. 2x Center may be used for 3x Wheel-SHORT
• Wheel or Wheel-SHORT , with domed or carved version of digits - as many as Center parts of same thickness

When assembling Wheel on Center you may need to push a spring a little

To take counter apart you may need something strong and flat (I used tweezers)
Usually I had no problems with this but on one print, where filament was thicker than normal, parts holded too strong and one broke

Optional files:

• For longer counters or to sepparate different parts (for example hp and exp on the same counter) add Stand-middle (same version as Stand-male)
• For multicolor print add Multicolor-addon file, the same as base file (for example Stand-TOP_Multicolor-addon on Stand-TOP) - set both models in the same spot in X and Y axis and merge them
• If you want a stronger spring (wheel will be harder to rotate but will also click louder) use Wheel_Spring-Extander. Set it in the same place as Wheel (one file works with all wheels) and merge both models Spring Extander is with flat 'frame' around it, it will not be printed, it's only there to easier set it in the right spot

Video with assembling and with clicking sound of the counter
https://www.instagram.com/p/DCWwb8-tvOd/

With this Commercial License you are authorized to:

Print — sell and distribute 3D prints of this 3D models and its adapted models for any use, including commercial use, in unlimited quantities;
Adapt — remix, transform and create from the digital files of the 3D model

What is not allowed:

No sharing of your 3D prints, nor adaptation of the 3D model without attribution.
No distribution, sale, donation or exchange of the digital files of the 3D model and the digital files of 3D models adapted from it.

If you will need any help with this models just write here or on my Instagram

If you want to sell just a few prints or want to sell it for some charity you can write to me too - this refers to every models of mine

Keep in mind that the price of the license is getting little highier after each purchase so the sooner you will buy it the cheaper it will be

Models prepared for 0.4mm nozzle but there should be no problems when using 0.1-0.5mm
Sliced with Arachne, not Classic engine
Printed with 0.16 and 0.2mm layer height
10% Gyroid infill (use more for Center if you plan to take counter apart)

Tested on 2 different printers with few different filaments
Best clicking sound was with simple, matt PLA. With Silk type it's little worse

If you don't know if your printer is set properly for used filament (it may differ) print only 2x Center model first and try joining them. If it's too hard to join (even when using more force) print it with less flow or with XY compensation / Horizontal expansion (you can start with maybe -0.01mm)
If it's too loose use more flow or positive XY compensation

To print in 2-3 colors on typical printer change color after height:
Stand - 0.16mm and 0.64mm
Wheel - 0.24mm and 0.96mm or 0.32 and 0.88
Wheel-SHORT - 0.04mm and 0.76mm or 0.12 and 0.68
You can also choose different heights as you like

For multicolor print you can paint models yourself in the slicer or use Multicolor-addon files
There is also a 3mf file I used for Bambu Lab A1 (should work for all Bambu prnters)

--
