mine model MI-AP-DV-1959

d13be3e0368dfad91e7e2d5d681b0a3a.jpg mine model MI-AP-DV-1959
Snimok-ekrana-2026-02-20-151109.png mine model MI-AP-DV-1959
Snimok-ekrana-2026-02-20-151115.png mine model MI-AP-DV-1959
MI-AP-DV-1959_BASE.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_COMBINED.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_SAFERTY_CAP.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_SHELL.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_STRIKER.stl mine model MI-AP-DV-1959
d13be3e0368dfad91e7e2d5d681b0a3a.jpg mine model MI-AP-DV-1959
Snimok-ekrana-2026-02-20-151109.png mine model MI-AP-DV-1959
Snimok-ekrana-2026-02-20-151115.png mine model MI-AP-DV-1959
MI-AP-DV-1959_BASE.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_COMBINED.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_SAFERTY_CAP.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_SHELL.stl mine model MI-AP-DV-1959
MI-AP-DV-1959_STRIKER.stl mine model MI-AP-DV-1959
Make an offer
Share
Add to
Make
?
Creation quality: 0/5 (0 votes)
Evaluation of members on the printability, utility, level of detail, etc.
License
Usages
3D design format
5 files (STL) Close
  • MI-AP-DV-1959_BASE.stl 65.999999 × 65.963144 × 7.0 mm
  • MI-AP-DV-1959_COMBINED.stl 65.999999 × 65.963144 × 66.8507 mm
  • MI-AP-DV-1959_SAFERTY_CAP.stl 52.0 × 53.223546999999996 × 26.000001 mm
  • MI-AP-DV-1959_SHELL.stl 62.242504 × 62.242502 × 37.669498000000004 mm
  • MI-AP-DV-1959_STRIKER.stl 29.966424000000004 × 29.966425 × 45.399997 mm

Learn more about the formats
Publication date
Design number 4059536
Design author 3DNW
3DNW

3DNW

Issue with this design? Report a problem.

3D printer file info

3D model description

📍 Information:
This is an antipersonnel high-explosive pressure mine. The mine's casing is made of polyethylene and contains no metal components. Detectability by induction mine detectors is ensured by a metal ring placed on the mine's top and the use of a metal R54 detonator cap. If a non-metallic ID 56 detonator cap is used and the metal ring is not installed, the mine will not be detected by the mine detector.

The mine can only be placed on or in the ground manually. It cannot be placed using mine spreaders. It is not designed to be unhandleable.

The mine detonates when the user steps on the target sensor, which is the detonator head. Target damage results in the severing of approximately a quarter to a third of the lower leg from the feet. Fatalities can sometimes occur due to traumatic shock.

The mine was adopted in 1959. As of 2016, this mine is not a standard issue mine in the French Army, as France signed the Ottawa Convention banning anti-personnel mines on July 23, 1998, and ratified it on March 1, 1999. However, it is studied at the French Army Engineering School.

🎓 Applications
- Educational purposes: studying the design - and operating principles
- Historical reenactment: museum displays, exhibitions, use as a replica.
- Collecting: for military history buffs, military exhibitions, visual familiarization (SAFE!)
- Tactical training: visual familiarization, detection training.

📋 Additional features

• Possibility of painting and post-processing
• All design features are precisely selected
• Ideal for museums, exhibitions, training, and demonstrations.

🛠 Specifications

  • File format: STL
  • Optimization: ideally prepared for 3D printing
  • Separation: Models are divided into logical sections

⚠️ Important Information ⚠️

WARNING: These models are 3D printable ONLY and do not contain explosives or functional components. They are intended for educational and demonstration purposes only.

3D printing settings

🔩 Technical Recommendations:
▪️Printer Type: FDM
▪️Preferred Plastic: PLA/PETG and equivalents
▪️Recommended Nozzle: 0.4

🔧 Recommended Print Settings:
🔸Infill 20%
🔸Infill Type: Gyroid
🔸Support Type: Tree-like (automatic)
